Description
The Connet 1064nm picosecond pulsed fiber laser is a reliable and maintenance-free laser designed for scientific research and industrial applications. It utilizes SESAM passive mode-locking technology and an optimized optical path to achieve stable linearly polarized picosecond laser output.
This all-polarization-maintaining fiber laser is suitable for use as a seed laser in high-power ultrafast pulsed fiber laser systems.
1064nm Picosecond Pulsed Fiber Laser
Specifications
Wavelength: | 1064 nm |
---|---|
Average Output Power: | 0.1 W |
Pulse Duration: | 0.005 – 0.05 ns |
Beam Quality (M^2): | 1.1 |
Max Pulse Repetition Rate: | 60000 kHz |
Spectral Width: | <1 nm |
Output Power: | >100 mW |
Polarization Extinction Ratio: | 20 dB |
Output Power Stability: | ±1 % |
Pulse Peak Stability: | 5 % |
Output Isolation: | 35 dB |
Operating Temperature: | +10 to +50 °C |
Storage Temperature: | -40 to +85 °C |
Supply Voltage: | 5.5-12 VDC |
Output Fiber Connector: | FC/APC (others available) |
Output Fiber Length: | >0.5 m |
Dimensions: | 150(L) x 125(W) x 25(H) mm |
Features
- All-fiber design based on SESAM passive mode-locking technology
- Linearly polarized output with high stability
- Pulse widths ranging from 5 to 50 picoseconds
- Repetition rates up to 60 MHz
- Narrow spectral width of less than 1nm
- Compact and robust construction
- Low amplitude noise and high beam quality
Applications
- Seed laser for fiber lasers and amplifiers
- Time precision detection
- Test and measurement applications
- Research and development
- LiDAR (Light Detection and Ranging) systems
Frequently Asked Questions
What are some applications of the Connet 1064nm picosecond pulsed fiber laser?
The laser can be used as a seed laser for fiber laser or amplifier, for time precision detection, test and measurement, R&D, and LiDAR.
What is the polarization of the laser output?
The laser output is linearly polarized.
What is the pulse width range of the laser?
The pulse width range of the laser is 5-50ps.
What is the repetition rate of the laser?
The repetition rate of the laser is 20-60MHz.
What is the wavelength of the Connet 1064nm picosecond pulsed fiber laser?
The wavelength of the Connet 1064nm picosecond pulsed fiber laser is 1064nm.
