Description
The Fiber-Coupled Cooled Superluminescent Diode (FESL-405-01-BTF) is a high-performance laser diode designed for various applications. It offers exceptional stability and reliability, making it an ideal choice for demanding optical projects.
Fiber-Coupled Cooled Superluminescent Diode - FESL-405-01-BTF
Specifications
| SLED Type: | Fiber Coupled |
|---|---|
| Operating Power (typical): | 2 mW |
| Center Wavelength (typical): | 405 nm |
| Bandwidth (FWHM): | 3 nm |
| Forward Current: | 110 mA |
| Reverse Voltage: | -5 V |
| Reverse Voltage: | 70 V |
| Storage Temperature: | -40 to +85 ℃ |
| Operating Temperature: | -20 to +65 °C |
| Storage Humidity: | 85 % |
| Operating Current: | 100 mA |
Download Data Sheet
Features
- High-quality fiber-coupled diode
- Cooled superluminescent diode design
- Wide operating temperature range (-20°C to 65°C)
- Low spectral ripple for precise measurements
- Compact and durable package design
- High forward current of up to 110 mA
Applications
- Fiber optic sensing
- Optical coherence tomography
- Biomedical imaging
- Industrial inspection and measurement
- Research and development in optics
Frequently Asked Questions
What is the Fiber-Coupled Cooled Superluminescent Diode (FESL-405-01-BTF)?
The Fiber-Coupled Cooled Superluminescent Diode (FESL-405-01-BTF) is a high-performance laser diode designed for various applications.
What are the features of the FESL-405-01-BTF?
The FESL-405-01-BTF features a high-quality fiber-coupled diode, a cooled superluminescent diode design, a wide operating temperature range (-20°C to 65°C), low spectral ripple for precise measurements, and a compact and durable package design.
What are some applications of the FESL-405-01-BTF?
The FESL-405-01-BTF can be used for fiber optic sensing, optical coherence tomography, biomedical imaging, industrial inspection and measurement, and research and development in optics.
What is the maximum forward current of the FESL-405-01-BTF?
The FESL-405-01-BTF has a high forward current of up to 110 mA.
What is the operating temperature range of the FESL-405-01-BTF?
The FESL-405-01-BTF has a wide operating temperature range of -20°C to 65°C.
