Compact and robust eye-safe micro Laser Rangefinder （mLRF）transceiver modules for kilometers NATO targets measuring and surveillance systems
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
-
On FindLight:
since 2019
Description
1.54 µm Eye-safe long distance laser rangefinder transceiver/module based on diode pumped monoblock microchip Er^3+, Yb^3+:Phosphate glass monolithic laser cavity transmitter with compact design and light weight assure OEM integration easy.
One series of such transceivers are commercially available upon request for OEM integrations based on monolithic laser cavity configurations for single pulse energy 100uJ,200uJ,300uJ,400uJ and 500uJ with range of 3km-12km at NATO targets 2.3m*2.3m.The modules are delivered without enclosure enabling OEM-users to embed the module into
their own systema or devices.
their own systema or devices.
Deep customization is welcome.
Compact and robust eye-safe micro Laser Rangefinder （mLRF）transceiver modules for kilometers NATO targets measuring and surveillance systems
Specifications |
|
|---|---|
| Measurement Range: | 500 – 10000000 mm |
| Resolution : | 500 mm |
| Ranging Capability (2.3m×2.3m Target): | ≥10 km |
| Wavelength: | 1535 nm |
| Divergence: | ≤0.3 mrad |
| CW Operation Frequency: | 1~10 Hz adjustable |
| Accuracy: | ≤±3 m (RMS) |
| False Report: | ≤2% |
| Resolution: | ≤50 m |
| Voltage: | DC9V～36V |
| Weight: | ≤240 g |
Features
• Ultra compact and lightweight
• Pulsed time-of-flight measurement
• Low power consumption
• Ranging capability up to 10000 m
• DPSS laser 1.54 µm wavelength
• Eye safe Class 1
Applications
• Reconnaissance
• Observation and surveillance
• Border and port control
• Off shore rescue
• Drone & UAV gimbals
• Handheld devices
• Sights
