Description
DLRF-C1.2-F semiconductor laser rangefinder is an innovative product that integrates advanced technology and humanized design carefully developed by LUMISPOT. Using a unique 905nm laser diode as the core light source, this model not only ensures human eye safety, but also sets a new benchmark in the field of laser ranging with its efficient energy conversion and stable output characteristics. Equipped with high-performance chips and advanced algorithms independently developed by LUMISPOT, the DLRF-C1.2-F achieves excellent performance with long life and low power consumption, perfectly meeting the market demand for high-precision and portable ranging equipment.
Lumispot 1.2km 905nm Laser Rangefinder Module With Good Price
Specifications
| Measurement Range: | 500 – 1200000 mm |
|---|---|
| Resolution : | 100 mm |
| Wavelength: | 905nm±5nm |
| Ranging Capacity: | 0.5~1200m (Building) |
| Ranging Accuracy: | ±0.5m (≤80m); ±1m (＞80m) |
| Resolution: | 0.1m |
| Ranging Frequency: | 60～800Hz （Self-Adaptive） |
| Accurate Ratio: | ≥98% |
| Beam Divergency: | ≤6mrad |
| Power Supply: | DC 3.0V~5.0V |
| Operating Power Consumption: | ≤1.8W |
| Standby Power Consumption: | ≤0.8W |
| Communication Type: | UART (TTL_3.3V) |
| Dimension: | 25×26×13mm |
| Weight: | 11g+0.5g |
| Operating Temperature: | -40°C~+ 60°C |
| Storage Temperature: | -45°C~+70°C |
| False Alarm Rate: | ≤1% |
Got questions about specs? Use the inquiry form to ask.
Download Data Sheet
Features
- High precision ranging data compensation algorithm: optimization algorithm, fine calibration
- Optimized ranging method: accurate measurement, improve ranging accuracy
- Low power consumption design: Efficient energy saving and optimized performance
- Working capacity under extreme conditions: excellent heat dissipation, guaranteed performance
- Miniaturized design, no burden to carry
Applications
Used in UAV, sighting, outdoor handheld products and other ranging applications (aviation, police, railway, electricity, water conservancy, communication, environment, geology, construction, fire station, blasting, agriculture, forestry, outdoor sports, etc.).
