Description
Discover the robust and resilient solution for demanding environments with our Radiation-Hard Multimode Fibers. Specially engineered to thrive in radiation-threatened areas, these fibers are the ideal choice for industries such as aerospace, where environmental conditions can be particularly harsh. Our fibers are not only designed to withstand radiation but also meet the stringent standards required for high-performance applications.
Our Radiation-Hard Multimode Fibers are rigorously tested and approved by the U.S. Defense Supply Center, Columbia (DSCC) in accordance with MIL-PRF 49291 specifications. Furthermore, these fibers adhere to and surpass the quality benchmarks set by ITU G.651, G.652, and IEC 60793-2-10, IEC 60793-2-50 standards. This commitment to quality ensures that each fiber delivers exceptional performance and reliability.
Every fiber undergoes a comprehensive quality test in line with the IEC 60793 standard. Additionally, our fibers are subjected to radiation resistance testing as per TIA/EIA 455-64 procedures, ensuring they maintain optimal performance even in the most challenging conditions. This meticulous attention to detail guarantees that our fibers provide consistent and reliable optical performance, making them the preferred choice for critical applications where failure is not an option.
Radiation-Hard Multimode Fibers - 62.5-125-245
Specifications |
|
|---|---|
| Core Diameter: | 62.5 um |
| Wavelength Range: | 850 – 1300 nm |
| Cable Length: | 1100 m |
| Fiber Core Material: | Not Specified |
| Coating Diameter: | 250 um |
| Cladding Diameter: | 125 um |
Features
- Radiation-Hard Design: Specially developed to withstand radiation hazards, ideal for aerospace and demanding environmental conditions.
- MIL-Spec Compliance: Approved by the U.S. Defense Supply Center, Columbia (DSCC) according to MIL-PRF 49291 standards.
- Quality Assurance: Meets and exceeds ITU G.651 and G.652, IEC 60793-2-10, and IEC 60793-2-50 standards.
- Comprehensive Testing: 100% quality tested as per IEC 60793 standards and radiation resistance tested via TIA/EIA 455-64 procedures.
- Temperature Range: Operating temperature from –55 °C to +85 °C; Storage temperature from –62 °C to +85 °C.
- Coating Specifications: Acrylate coating with a temperature range of –55 °C to +85 °C, available in 245 μm and 500 μm diameters.
- Coating Strip Force: 1.8 ≤ F ≤ 13.2 N for 245 μm coating, 1.8 ≤ F ≤ 20
Applications
- Aerospace Industries: Designed to withstand radiation and demanding environmental conditions, making them suitable for aerospace applications.
- Military Applications: Approved by the U.S. Defense Supply Center, Columbia (DSCC) according to MIL-PRF 49291, ensuring reliability in military settings.
- Telecommunications: Meets ITU G.651 and G.652 standards for optical fibers, making them suitable for telecommunications infrastructure.
- Industrial Environments: Resistant to radiation and harsh conditions, ideal for use in industrial environments where reliability is critical.
- Scientific Research: Used in environments with high radiation exposure for scientific experiments and research purposes.
- Medical Equipment: Suitable for use in medical equipment that requires reliable fiber optics under radiation exposure.
- Space Missions: Withstands extreme temperatures and radiation, making them ideal for space exploration and satellite communication.
Frequently Asked Questions
Radiation-hard multimode fibers are specially developed for applications in aerospace industries to withstand hazards in radiation-threatened areas or under demanding environmental conditions.
These fibers were tested and approved by the U.S. Defense Supply Center, Columbia (DSCC) according to MIL-PRF 49291.
These fibers meet and exceed the quality standards of the ITU G.651 and G.652 or IEC 60793-2-10 and IEC 60793-2-50.
The temperature range for the coating is -55 °C to +85 °C.
The attenuation at 850 nm/1300 nm is 3.5 / 1.0 dB/km.
