Description
Experience unparalleled performance and reliability with our radiation-hard multimode fibers, designed specifically for demanding environments such as aerospace industries. These fibers are meticulously engineered to withstand the challenges of radiation-threatened areas, ensuring optimal functionality under the most strenuous conditions. Our fibers are not just built to endure; they are crafted to excel, providing a robust solution for those who require the utmost in durability and quality.
Our radiation-hard multimode fibers adhere to the stringent standards set by the U.S. Defense Supply Center, Columbia (DSCC), as they are tested and approved according to MIL-PRF 49291 specifications. Beyond meeting these military specifications, these fibers also exceed the quality benchmarks of ITU G.651 and G.652, as well as IEC 60793-2-10 and IEC 60793-2-50. Every fiber undergoes a comprehensive 100% quality test in line with the IEC 60793 standard, ensuring that each fiber not only meets but surpasses industry expectations.
Our fibers are rigorously tested for radiation resistance following the TIA/EIA 455-64 procedure, which measures radiation-induced attenuation in optical fibers. This ensures that our fibers maintain their integrity and performance even in high-radiation environments. With a focus on optical properties, mechanical strength, and environmental resilience, these fibers provide a reliable solution for critical applications. The combination of superior materials and advanced engineering results in a product that stands at the forefront of fiber optic technology, offering unmatched reliability and performance in the most challenging settings.
Radiation-Hard Multimode Fibers - 50-125-245
Specifications |
|
|---|---|
| Core Diameter: | 50 um |
| Wavelength Range: | 850 – 1300 nm |
| Cable Length: | 1100 m |
| Fiber Core Material: | Not Specified |
| Cladding Diameter: | 125 um |
| Coating Diameter: | 245 um |
Features
- Radiation-Hard Design: Specially developed for aerospace and demanding environmental conditions, these fibers are designed to withstand radiation-threatened areas.
- MIL-Spec Approved: Tested and approved by the U.S. Defense Supply Center, Columbia (DSCC) according to MIL-PRF 49291 standards.
- High-Quality Standards: Meets and exceeds ITU G.651 and G.652, IEC 60793-2-10, and IEC 60793-2-50 standards.
- Comprehensive Quality Assurance: Each fiber undergoes a 100% quality test as per IEC 60793 and radiation resistance testing according to TIA/EIA 455-64.
- Optical Properties: Available in various core sizes (50/125/245 μm, 50/125/500 μm, 62.5/125/245 μm, 62.5/125/500 μm) with low attenuation rates and high bandwidth capabilities.
- Temperature Resilience: Operates efficiently across a wide temperature range from -55 °C to +85 °C, with storage capabilities from -62 °C to +85 °C.
- Mechanical Durability: Features a robust proof test of ≥ 690 MPa and dynamic tensile strength of ≥ 3.2 GPa (unaged).
- Coating Specifications: Acrylate coating with a temperature range of –55 °C to +85 °C, ensuring protection and durability.
- Lightweight and Long Lengths: Fiber weight is ≤ 0.25 kg/km with lengths of ≥ 1.1 km, making it suitable for extensive installations.
- Consistent Performance: Core/cladding concentricity error and overall coating concentricity ratio (OCCR) ensure reliable optical performance.
Applications
- Aerospace Industries: Designed to withstand radiation hazards and demanding environmental conditions.
- Defense and Military Applications: Approved by the U.S. Defense Supply Center, Columbia (DSCC) according to MIL-PRF 49291 standards.
- Telecommunications: Meets ITU G.651 and G.652 standards for quality and performance.
- High-Radiation Environments: Resistant to radiation, tested according to TIA/EIA 455-64 for radiation-induced attenuation.
- Industrial Applications: Suitable for use in environments where radiation resistance is critical.
- Scientific Research: Ideal for use in research settings where exposure to radiation is a factor.
Frequently Asked Questions
These fibers meet and exceed the quality standards of the ITU G.651 and G.652 or IEC 60793-2-10 and IEC 60793-2-50. They were also tested and approved by the U.S. Defense Supply Center, Columbia (DSCC) according to MIL-PRF 49291.
Radiation-hard multimode fibers are fibers that are specially developed to withstand the hazards in radiation-threatened areas or under demanding environmental conditions, such as those found in aerospace industries.
The core diameter of these fibers is either 50 or 62.5 micrometers.
The temperature range for the coating is -55°C to +85°C.
The proof test for these fibers is at least 690 MPa.
