ModCon Mode Controller MC-SC-62-E-85
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United Kingdom
-
Sold by:
-
On FindLight:
since 2015
Description
Measurements of loss and bandwidth in multimode fibers are known to be highly dependent on the modal condition of the light source used for the measurement. For example, OTDR and LS/PM loss measurements can differ significantly simply because an OTDR uses a laser source and not an LED. Now there is a way to dramatically improve agreement AND ensure you meet international standards at the same time - the ModCon. The ModCon is a passive device which ensures that the correct launch conditions are achieved independent of the light source used. This results in more accurate measurements, better agreement between different test sets, and compliance with the 85/85% launch conditions called for in various aerospace standards. Every ModCon is tested using an MPX Modal Explorer to ensure that its output meets the standard regardless of the modal distribution of the input.
ModCon Mode Controller MC-SC-62-E-85
Specifications |
|
|---|---|
| Insertion Loss @ 850nm 50µm: | < 5.0dB |
| Insertion Loss @ 850nm 62.5µm: | < 5.0dB |
| Dimensions: | 165mm x 105mm x 32mm |
| Weight: | 380gm |
| Intensity 5% Maximum Value: | 55 µm |
| Intensity 5% Minimum Value: | 51 µm |
| Intensity 15% Maximum Value: | 52 µm |
| Intensity 15% Minimum Value: | 45 µm |
| Intensity 75% Maximum Value: | 33 µm |
| Intensity 75% Minimum Value: | 20 µm |
| Intensity 5% Maximum Value: | 44.0 µm |
| Intensity 5% Minimum Value: | 40.8 µm |
| Intensity 15% Maximum Value: | 41.6 µm |
| Intensity 15% Minimum Value: | 36.0 µm |
| Intensity 75% Maximum Value: | 26.4 µm |
| Intensity 75% Minimum Value: | 16.0 µm |
Features
- Source Independent Mode Control: The ModCon Mode Controller ensures stable and accurate launch conditions for multimode fiber measurements, regardless of the light source used.
- Improved Measurement Accuracy: Achieve more precise measurements and better agreement between different test sets by fitting the ModCon to your light source.
- Compliance with Aerospace Standards: The device meets the 85/85% launch conditions required by various aerospace standards, ensuring your measurements are up to standard.
- Passive Device: The ModCon is a passive device that requires no power, simplifying integration into your existing setup.
- Tested for Quality: Each ModCon is tested using an MPX Modal Explorer to ensure output meets the required standards, regardless of input modal distribution.
- Easy Integration: Simply fit the ModCon between the test set and the Fiber Under Test for seamless operation.
- Technical Specifications:
- Insertion Loss @ 850nm: 50µm typically < 5.0dB, 62.5µm typically < 5.0dB
- Dimensions: 165mm x 105mm x 32mm
- Weight: 380gm
- Modal Launch Conditions: Available with a Certificate of Conformance or Test Certificate (850 and 1300nm) detailing measurement specifics.
- Product Variants:
- MC-FC-50-E-85: Mode control patchcord with FC connectors for 85/85% modal launch into 50µm core fiber from 850 or 1300nm light source.
- MC-FC-62-E-85: Mode control patchcord with FC connectors for 85/85% modal launch into 62.5µm core fiber from 850 or 1300nm light source.
Applications
- Improve your measurement accuracy: The ModCon ensures stable launch conditions for multimode fiber measurements.
- Ensure stable launch conditions: Achieve consistent results across different test sets and light sources.
- Meet 85/85% launch conditions: Comply with international aerospace standards for modal launch conditions.
- Measurements of loss and bandwidth: Reduce dependency on the modal condition of the light source for accurate readings.
- OTDR and LS/PM loss measurements: Minimize discrepancies between different measurement techniques.
- Passive device: The ModCon works with any light source to achieve the correct launch conditions.
- Compliance with aerospace standards: Ensure measurements meet the required standards for aerospace applications.
- Tested with MPX Modal Explorer: Every ModCon is verified to meet standards regardless of input modal distribution.
- Easy integration: Simply fit the ModCon between the test set and the Fiber Under Test.
Frequently Asked Questions
The ModCon Mode Controller is a passive device that ensures the correct launch conditions are achieved independent of the light source used for multimode fiber measurements.
The ModCon ensures stable launch conditions for multimode fiber measurements, resulting in more accurate measurements and better agreement between different test sets.
The ModCon ensures compliance with the 85/85% launch conditions called for in various aerospace standards.
Every ModCon is tested using an MPX Modal Explorer to ensure that its output meets the standard regardless of the modal distribution of the input.
The ModCon has an insertion loss of <5.0dB at 850nm for both 50µm and 62.5µm fibers, and its dimensions are 165mm x 105mm x 32mm with a weight of 380gm. The Modal Launch Conditions for our Aerospace modal controllers is specified in terms of the width of the Near Field Pattern at 5, 15 and 75% of the maximum.
