Description
The Shamrock 163 is a state-of-the-art Czerny-Turner spectrograph, renowned for its compact design and exceptional performance. With a focal length of 163 mm and an aperture of F/3.6, it stands out as the most compact research-grade spectrograph available today. Its user-friendly design allows for both horizontal and vertical mounting positions, making it highly portable and easy to integrate into various spectroscopy setups.
This benchtop spectrograph is engineered to accommodate a wide array of interchangeable gratings, slits, and light coupling interfaces. This flexibility ensures that users can seamlessly adapt the Shamrock 163 to meet specific experimental needs, whether for general spectroscopy measurements or more specialized applications. The precision locking mechanism for gratings allows for easy upgrades and modifications, ensuring that the device can evolve alongside advancing research requirements.
The Shamrock 163 is not only compact but also highly configurable for sophisticated multi-track spectroscopy. Its imaging-configurable platform, complemented by lens-based accessories, is designed to optimize system performance by minimizing cross-talk and enabling simultaneous acquisition of multi-leg fiber signals. This makes it an ideal choice for researchers looking to conduct detailed and accurate spectroscopic analysis.
Customization of the Shamrock 163 is straightforward, with clear steps for configuring the chassis, resolution, band-pass, and input light coupling interface. Researchers can select from a variety of optics coatings and software interfaces to tailor the spectrograph to their specific needs. Whether using the state-of-the-art Solis software or the Software Development Kit (SDK), the Shamrock 163 ensures a seamless integration with Andor detectors, providing a comprehensive solution for advanced spectroscopy.
Shamrock 163 Spectrograph - SR1-GRT-0600-0500
Specifications |
|
|---|---|
| Monochromator Type: | Czerny-Turner |
| Effective Focal Length: | 163 mm |
| Diffraction Grating: | 600 lines/mm |
| Grating Blaze Wavelength: | 500 nm |
| Spectral Range: | 250 – 1300 nm |
| Linear Dispersion (Avg): | 9.25 nm/mm |
| Spectral Resolution (Avg): | 0.55 nm |
Features
- Compact & Rugged Design: The Shamrock 163 offers both horizontal and vertical mounting positions, ensuring portability and ease of integration.
- Imaging-Configurable Platform: Designed for multi-track spectroscopy, with lens-based accessories to optimize system performance for low cross-talk and simultaneous multi-leg fibre signal acquisition.
- Interchangeable Gratings: Features a wide range of gratings with a simple precision locking mechanism for seamless upgradability.
- Variety of Fixed Slits: Includes interchangeable laser-cut precision slits with widths ranging from 10 µm to 200 μm.
- Large Choice of Light Coupling Interfaces: Offers options including fibre-optics and C-mount microscope couplers.
- Calibrated Micrometer Drive: Allows for simple and rapid wavelength adjustment for precise wavelength selection.
Applications
- General Benchtop Spectroscopy: Ideal for versatile research-grade spectral measurements.
- Multi-Track Fibre Spectroscopy: Supports simultaneous signal acquisition with low crosstalk.
- Raman and Fluorescence Spectroscopy: Suitable for high-resolution spectral analysis in chemical and material sciences.
- Educational and Research Laboratories: Provides a compact and flexible spectroscopy platform for academic environments.
- Industrial Spectroscopy Integration: Reliable performance for quality control and optical system development.
Frequently Asked Questions
The Shamrock 163 has a compact and rugged design with horizontal and vertical mounting positions for portability and ease of integration. It also has a wide range of interchangeable gratings, fixed slits, and light coupling interfaces for optimization of system performance and simultaneous acquisition of multi-leg fiber signals.
The Shamrock 163 is available in two models: the SR-163 base unit for spectrally optimized configuration and the SR-163-SIL base unit for spectrally optimized configuration with protected silver coated optics. The standard optics coatings are aluminum and MgF2, but protected silver coated optics are available upon request.
The Shamrock 163 has a resolution of 0.25 nm with a Newton DU940 CCD and 1200 l/mm at 500 nm and 2400 l/mm at 300 nm. It has an aperture of F/3.6 and a focal length of 163 mm. It also has a single, interchangeable grating and a variety of fixed and adjustable slits.
To customize the Shamrock 163, you need to select the appropriate chassis configuration, gratings, and detector for your resolution and band-pass requirements. You also need to select the input light coupling interface and software interface.
The Shamrock 163 is a compact research-grade Czerny-Turner spectrograph that is ideal for general benchtop spectroscopy measurements.
