Blazed Holographic Grating 530 60
Description
HORIBA Jobin Yvon has produced a wide range of blazed holographic master gratings from which we manufacture high precision replicas.
Our replica gratings retain the advantages of our master holographic gratings:
❏ Perfect periodicity, plus excellent micro-roughness of the surface eliminates ghosts and enhances stray light rejection
❏ Minimal groove errors provide very high resolution
In addition, owing to their ion-etched, sawtooth groove profiles, these gratings offer higher peak efficiency than standard holographic gratings.
Blazed Holographic Grating 530 60
Specifications |
|
|---|---|
| Groove Density: | 950 l/mm |
| Spectral Range: | 700-1700nm |
| Blaze: | Blazed |
| Blaze Wavelength: | 900 nm |
| Dimension (Length): | 110 mm |
| Dimension (Height): | 110 mm |
| Dimension (Thickness): | 16 mm |
| Substrate Material: | Fused Silica, NBK7, Pyrex, Zerodur, ULE, Metallic, Custom |
Features
Standard substrate material is Pyrex; on request, substrates including fused silica, Zerodur, ULE, metals, or other materials can be considered. Standard coating is aluminium. On request, AlMgF2, gold or platinum are also available for an additional cost.
Applications
Spectrometers
Spectroscopy
Beam isolation
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2016
Frequently Asked Questions
HORIBA Jobin Yvon offers complete customer service, including expert technical advice for optimizing system configurations to meet customers’ needs. They are ISO9001:2000 certified, and their well-staffed departments are committed to customer satisfaction and product quality.
Blazed holographic master gratings are a type of high precision replica grating produced by HORIBA Jobin Yvon. They offer perfect periodicity and excellent micro-roughness of the surface, which eliminates ghosts and enhances stray light rejection.
The standard substrate material for the gratings is Pyrex. However, substrates including fused silica, Zerodur, ULE, metals, or other materials can be considered upon request.
The standard coating for the gratings is aluminium. However, AlMgF2, gold or platinum are also available upon request for an additional cost.
Blazed holographic gratings can be used in spectrometers, spectroscopy, and beam isolation.
