High-Precision Cube Beamsplitter for Versatile Optical Applications
Minyi Technology
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
Minyi Technology -
On FindLight:
since 2025
Description
Our high-precision beamsplitters are designed to meet the rigorous demands of modern optical and laser systems. With exceptional beam deviation of ±3 arc minutes and a surface quality of 40-20 S-D, these beamsplitters ensure precise and reliable light manipulation in various applications.
High-Precision Cube Beamsplitter for Versatile Optical Applications
Minyi Technology
Specifications |
|
|---|---|
| Material: | N-BK7 |
| Wavelength Range: | 400 – 700 nm |
| Max Beam Deviation: | 3 arcmin |
| Beam Deviation: | ±3 arcmin |
| Surface Quality: | 40-20 S-D |
| Surface Flatness: | <λ/4@632.8 nm |
| Clear Aperture: | 90% |
| Dimension Tolerance: | ±0.2 mm |
Features
- Exceptional Surface Flatness: With a flatness of <λ/4@632.8 nm, our beamsplitters maintain wavefront integrity, making them ideal for high-precision laser systems.
- High Transmission Efficiency: Boasting a 90% clear aperture, these beamsplitters maximize light throughput while minimizing distortion.
- Customizable Coating Options: Coatings can be tailored upon request to suit specific wavelength and reflection/transmission ratio requirements.
- Tight Dimension Tolerance: Manufactured with a strict tolerance of ±0.2 mm, ensuring compatibility with precision optical setups.
Applications
- Beamsplitters are used to split or combine beams of light.
- The most common types of beamsplitters are plates and cubes.
- Plates are used for most laser applications as they exhibit low absorption.
- Cubes are a convenient, protected form for low power applications.
Frequently Asked Questions
The beam deviation is ±3 arcmin.
The surface quality is 40-20 S-D.
The surface flatness is less than λ/4 at 632.8 nm.
The clear aperture is 90%.
The dimension tolerance is ±0.2 mm.
Yes, coating is available upon request.
The most common types of beamsplitters are plates and cubes.
