Thumbnail of Custom Calorimeter 532nm Rectangular Aperture photo 1

Description

Gentec-EO's Calorimeters are the pinnacle of reliability for measuring laser beams, particularly for the most substantial and highest energy laser beams. These calorimeters, crafted with precision and expertise, offer unrivaled performance for high-energy inertial confinement fusion calorimetric measurements.

With over 40 years of experience, Gentec-EO has become the foremost authority in manufacturing, calibrating, and servicing calorimeters, ensuring the highest level of accuracy and repeatability in energy measurement.

Custom Calorimeter 532nm Rectangular Aperture

Visit the Gentec-EO Store

Specifications

Aperture Shape: Rectangular
Aperture Size (larger Dimension): 230 mm
Spectral Range: 1053 nm, 532 nm
Maximum Energy: 5000 J

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Customized Solutions: Designed for a wide range of applications, from 16 kJ beams to delicate 50 mJ applications
  • Wide Spectral Range: Covers wavelengths from 190 nm to 25 microns, with the ability to push these limits even further
  • Accuracy: NIST traceable sources and calibration techniques ensure calibration uncertainties of ±3%
  • High Sensitivity: Offers outstanding signal-to-noise ratios for precise measurements.
  • Vacuum Compatibility: Suitable for use in vacuum environments
  • Attention to Detail: Craftsmanship honed over four decades of experience in thermal-based energy measurement

Applications

  • Laser Fusion Experiments: Used to measure the energy generated in inertial confinement fusion experiments where laser beams rapidly heat the fusion target, replicating energy processes in the sun's core
  • Femtosecond Lasers: Essential for high-power femtosecond lasers with peak powers in the Petawatts range and beam sizes too small for standard detectors
  • Power Measurement: Ideal for high-energy laser pulses and power measurement applications

Frequently Asked Questions

What is a Gentec-EO calorimeter?
A Gentec-EO calorimeter is a reliable solution for measuring high energy laser beams. It is manufactured, calibrated, and serviced by Gentec-EO, which has become an expert in this field.
What are the features of the Gentec-EO calorimeter?
The Gentec-EO calorimeter has outstanding signal to noise ratios, high sensitivity, vacuum compatibility, and attention to detail and workmanship.
What is the accuracy of the Gentec-EO calorimeter?
The Gentec-EO calorimeter is the most accurate large aperture measurement device on the market, with calibration uncertainties of ±3% and repeatabilities better than ±2% for very large beams.
What is the range of beam energies that the Gentec-EO calorimeter can measure?
The Gentec-EO calorimeter can measure beam energies ranging from 50 mJ to 16 kJ, and it spans the band from 190 nm to 25 microns.
What is the application of the Gentec-EO calorimeter?
The Gentec-EO calorimeter is used in inertial confinement fusion (ICF) experiments, where high-energy beams of laser light are used to compress and heat a fuel target to initiate nuclear fusion reactions.

Got more questions? Use the inquiry form to ask the supplier directly.
