Page 3 - Photomultiplier Tubes (PMT)

Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9266B is a 51mm (2”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode and 10 high gain, high stability, SbCs dynodes of linear focused design for good linearity and timing. The 9266QB is a variant for applications ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 4 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9235B is a 51mm (2”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode and 13 high gain, high stability, SbCs dynodes of linear focused design.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 200 nm
Wavelength Range: 160-630nm
Rise Time: 3 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9235B is a 51mm (2”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode and 13 high gain, high stability, SbCs dynodes of linear focused design. The 9235QB is a variant for applications requiring UV sensitivity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 3 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9214B is a 51mm (2”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathode and 12 high gain, high stability, SbCs dynodes of linear focused design .

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 2 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9143B is a 30 mm (1.13”) diameter end window photomultiplier with plano concave window, blue-green sensitive bialkali photocathode and 11 high gain, high stability, SbCs dynodes of linear focused design for good linearity and timing. The 9143WB is a ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-630nm
Rise Time: 2 ns
Data Sheet
The 9136B is a 29 mm (1.13 \") diameter, end window photomultiplier with S20 infra red sensitive photocathode and 11 high gain, high stability, SbCs dynodes of linear focused design for extended linearity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-850nm
Rise Time: 3 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9128B is a 29 mm (1.13\") diameter, end window photomultiplier with plano-concave window, blue-green sensitive bialkali photocathode and BeCu dynodes of linear focused design for high pulsed linearity. The 9128QB is a variant for applications requiring UV ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-630nm
Rise Time: 2.5 ns
Data Sheet
Photomultiplier Tube (PMT) from ADIT Electron Tubes.The 9124B is a 29 mm (1.13\") diameter, end window photomultiplier with enhanced green sensitive bialkali photocathode and 11 high gain, high stability, SbCs dynodes of linear focused design. The 9124QB is a variant for applications requiring UV sensitivity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-680nm
Rise Time: 3 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9116B is a compact 25mm (1”) diameter, end window photomultiplier with a hemispherical window for 2π detection, enhanced green sensitive bialkali photocathode and 6 high gain, high stability, SbCs dynodes of circular focused design for fast timing. The ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 295-680nm
Rise Time: 1.8 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9114B is a compact 25 mm (1\") diameter, end window photomultiplier with hemispherical window for 2π detection, blue-green sensitive bialkali photocathode and 10 high gain, high stability, SbCs dynodes of circular focused design for fast timing.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 375 nm
Wavelength Range: 295-630nm
Rise Time: 1.8 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9112B is a compact 25 mm (1\") diameter, end window photomultiplier with plano-concave window, enhanced green sensitive bialkali photocathode and 10 high gain, high stability, SbCs dynodes of circular focused design for fast timing. The 9112WB is a variant ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-630nm
Rise Time: 1.8 ns
Data Sheet
Photomultiplier Tub (PMT) by ADIT Electron Tubes.The 9111WB is a compact 25 mm (1”) diameter, end window photomultiplier with plano-concave window, UV sensitive biakali photocathode and 10 high gain, high stability, SbCs dynodes of circular focused design for fast timing

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 170-630nm
Rise Time: 1.8 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9111B is a compact 25 mm (1”) diameter, end window photomultiplier with plano-concave window, blue-green sensitive biakali photocathode and 10 high gain, high stability, SbCs dynodes of circular focused design for fast timing. The 9111WB is a variant for ...

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-630nm
Rise Time: 1.8 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes. The 9107B is a 29 mm (1.13”) diameter end window photomultiplier with blue-green sensitive bialkali photocathode and 11 high gain, high stability, SbCs dynodes of linear focused design. The 9107QB is a variant for applications requiring UV sensitivity.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-630nm
Rise Time: 4.5 ns
Diameter: 29
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes. Variant of 9106B with quartz window for UV sensitivity to 165nm. The 9106B is a 29 mm (1.13”) diameter end window photomultiplier with enhanced green sensitive bialkali photocathode and 7 high gain, high stability, SbCs dynodes of linear focused design.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 165-680nm
Rise Time: 4.5 ns
Diameter: 29 mm
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes. The 9106B is a 29 mm (1.13”) diameter end window photomultiplier with enhanced green sensitive bialkali photocathode and 7 high gain, high stability, SbCs dynodes of linear focused design. The 9106QB is a version with a quartz window for extended UV sensitivity

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-680nm
Rise Time: 4.5 ns
Diameter: 29 mm
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes. The 9102B is a 38 mm (1.5”) diameter, end window photomultiplier with blue-green sensitive bialkali photocathodeand 10 high gain, high stability, SbCs dynodes of linear focused design for good linearity and timing.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 290-630nm
Rise Time: 3.5 ns
Diameter: 38 mm
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9086FLB is a 19 mm (0.75”) diameter, end window photomultiplier with plano-concave window, S20 infra-red sensitive photocathode and 10 BeCu dynodes of linear focused design for good linearity and timing.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-800nm
Rise Time: 1.8 ns
Diameter: 19 mm
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9085B is a 19 mm (0.75”) diameter, end window photomultiplier, with enhanced green sensitive bialkali photocathode and 10 high gain, high stability SbCs dynodes of linear focused design.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 280-680nm
Rise Time: 1.8 ns
Diameter: 19 mm
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.The 9078B is a 19 mm (0.75\") diameter end window photomultiplier with blue-green sensitive bialkali photocathode and 10 high gain, high stability SbCs dynodes of linear focused design.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 350 nm
Wavelength Range: 280-630nm
Rise Time: 1.8 ns
Diameter: 19 mm
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes. The 6097B is a 51 mm (2\") diameter, end window photomultiplier with enhanced green sensitive bialkali photocathode and 11 high gain, high stability, SbCs dynodes of the long-established venetian blind design providing a low afterpulse rate.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 400 nm
Wavelength Range: 290-680nm
Rise Time: 10 ns
Data Sheet
Photomultiplier Tube (PMT) by ADIT Electron Tubes.

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 380 nm
Wavelength Range: 290-630nm
Rise Time: 2 ns
Data Sheet
ADIT Electron Tubes manufactures a full range of photomultipliers.The ADIT brand is a manufactured in west Texas.The Electron Tubes brand is manufactured in west London

Specifications

PMT Type: PMT (photomutiplier tube)
Wavelength Of Max Response: 390 nm
Wavelength Range: 110-900nm
Rise Time: 2 ns
Data Sheet
