CMOSIS CMV20000 Mono 5K Embedded Camera

Ximea
REQUEST QUOTE
CMOSIS CMV20000 Mono 5K Embedded Camera

OVERVIEW

These cameras are the backbone of the xiFLY platform. They are small, lightweight cameras with fl exible ribbon cable interfaces. Alternatively, they can be adapted to fi ber optic cabling. The small board stack in  these cameras makes for fantastic fl exibility in systems with tight spatial requirements. Together with the xiFLY accessories, the xiX cameras drive performance in small spaces, from great distances, and at high speed. For embedded solutions, have a look at our carrier boards xEC2 for the computing platforms by NVIDIA (Jetson TX2, Xavier in preparation). With these and other 3rd party vendors, it is possible to build extremely compact subsystems, even mobile units, supporting multiple cameras.

SPECIFICATION

  • Sensor Type: CMOS
  • # Pixels (Width): 5120
  • # Pixels (Height): 3840
  • Pixel Size (Square): 6.4 um
  • Peak Quantum Efficiency: -- %
  • Full Frame Rate: 33 fps
  • Bit Depth: 12 bit
Download Data Sheet

Applications

VisionInspection
OEM
Metrology
Scientific

KEY FEATURES

Compatible with the xiFLY platform
Power and GPIO is fed through the ribbon cable reducing the need for extra cables
Super compact form factor
Connector options to fit your needs
Ideal for embedded applications and tight spaces
No frame grabber required, DMA transfer with no CPU load
Direct GPU transfer with selected NVIDIA boards under Linux
Data transmission with functionally zero latency
Flexible GPIO with optoisolated and TTL options
Low power consumption
Rugged and lightweight, aluminum alloy CNC machined housing
