Description
Welcome to Optical Instrument Lab, Inc., where precision meets innovation in the realm of optical components and manufacturing. Our company is renowned for its ability to deliver high-quality optical solutions with remarkable efficiency, catering to both high volume and specialized requirements. We pride ourselves on our capability to handle projects demanding medium to high tolerances and varying diameter specifications, ensuring that each product meets the exacting standards of our clients.
At Optical Instrument Lab, Inc., we maintain a vast inventory of optical materials, allowing us to respond swiftly to diverse manufacturing needs. Our expertise in precision manufacturing is supported by advanced techniques such as Blanchard Grinding, Cylindrical Grinding and Polishing, and both Single-Sided and Double-Sided Lapping and Polishing. These capabilities enable us to achieve exceptional flatness and surface finish, essential for high-performance optical components.
Our commitment to quality is evident in our stringent adherence to specifications and tolerances. We work within a broad range of dimensions, accommodating diameters from as small as 0.0100" to as large as 36" square, and thicknesses from 0.007" to 3.5". Our precision extends to maintaining tolerances with diameters within 0.001", flatness to 1/4 wave, and surface finishes ranging from 20/10 to 60/40. This meticulous attention to detail ensures that our products consistently meet the highest standards of excellence.
Discover the difference that Optical Instrument Lab, Inc. can make for your optical component needs. Our dedication to precision, quality, and customer satisfaction sets us apart as a leader in the optical manufacturing industry. For more information about our products and notable projects, we invite you to explore our offerings and see why we are the preferred choice for discerning clients worldwide.
Optical Instrument Laboratory Services
Specifications |
|
|---|---|
| Type Of Service: | Engineering design, Industrial design, Manufacturing design |
Features
- Large Inventory of Optical Materials: Access to a wide range of high-quality optical materials to meet diverse manufacturing needs.
- Precision Surface Quality: Achieve scratch dig to 20 - 10 and flatness to 1/4 wave for superior optical performance.
- Versatile Size Capabilities: Manufacture components from 1/4" diameter to 36" square, accommodating various project requirements.
- Advanced Grinding Techniques: Utilize Blanchard Grinding and Cylindrical Grinding for precise shaping and finishing.
- Expert Blocking: Employ Pitch & Wax blocking methods for secure and accurate component handling.
- Comprehensive Lapping and Polishing: Offer large plate, double-sided, and single-sided lapping and polishing for optimal surface finishes.
- Precision Drilling and Slicing: Provide drilling, grinding, and slicing services for intricate component designs.
- Wide Range of Specifications: Work with diameters from .0100" to .28" and square/rectangle sizes from .0100" to 36".
- Thickness Versatility: Handle thicknesses ranging from .007" to 3.5" to suit various application needs.
- Strict Tolerance Control: Maintain diameter tolerances within .001" and flatness to 1/4 wave for precision manufacturing.
- Surface Finish Excellence: Deliver surface finishes ranging from 20/10 to 60/40 for high-quality optical components.
- Exceptional Parallelism: Ensure parallelism within .0001" to .0005" for precise alignment and performance.
Applications
- Optical Lenses & Windows: High-precision optics for imaging and laser systems.
- Prisms & Beam Splitters: Components for laboratory and industrial optical setups.
- Research & Development: Rapid prototyping and specialized optical experiments.
- Industrial Manufacturing: Optical elements for sensors, instrumentation, and devices.
Frequently Asked Questions
The product features a large inventory of optical materials, scratch dig to 20 - 10, flatness to 1/4 wave, 1/4" diameter to 36" square, Blanchard Grinding, Blocking: Pitch & Wax, Cylindrical Grinding and Polishing, Large Plate Lapping and Polishing, Double-Sided Lapping and Polishing, Single-Sided Lapping and Polishing, Drilling, Grinding, and Slicing.
The product generally works within the following range, but is not limited to: Diameter: .0100" - .28", Square/Rectangle Sizes: .0100" - 36", Thickness: .007" - 3.5".
The product generally works within the tolerance range, but is not limited to: Diameter: within .001", Flatness: 1/4 wave, Surface Finish: 20/10 - 60/40", Parallelism: .0001" - .0005".
Optical Instrument Lab, inc. specializes in providing short manufacturing times for high volume manufacturing requiring medium to high tolerances and multiple diameter variances.
You can find more information about the products and services offered by Optical Instrument Lab, inc. on their website, including their products page and projects page.
