Blazed Holographic Grating 530 20

Name: Blazed Holographic Grating 530 20
Brand: HORIBA
Availability: InStock

Description

HORIBA Jobin Yvon has produced a wide range of blazed holographic master gratings from which we manufacture high precision replicas.
Our replica gratings retain the advantages of our master holographic gratings:
❏ Perfect periodicity, plus excellent micro-roughness of the surface eliminates ghosts and enhances stray light rejection
❏ Minimal groove errors provide very high resolution

In addition, owing to their ion-etched, sawtooth groove profiles, these gratings offer higher peak efficiency than standard holographic gratings.

Specifications

Groove Density:	1800 l/mm
Spectral Range:	190 – 700 nm
Blaze:	Blazed
Blaze Wavelength:	250 nm
Dimension (Length):	110 mm
Dimension (Height):	110 mm
Dimension (Thickness):	16 mm
Substrate Material:	Fused Silica, NBK7, Pyrex, Zerodur, ULE, Metallic, Custom

Download Data Sheet

Features

Standard substrate material is Pyrex; on request, substrates including fused silica, Zerodur, ULE, metals, or other materials can be considered. Standard coating is aluminium. On request, AlMgF2, gold or platinum are also available for an additional cost.

Applications

Spectrometers

Spectroscopy

Beam isolation

Add to Watchlist (My Watchlist)

Ships from:

United States

Sold by:

HORIBA

On FindLight:

since 2016

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What are blazed holographic gratings?

Blazed holographic gratings are high precision replicas of master holographic gratings produced by HORIBA Jobin Yvon. They have perfect periodicity and excellent micro-roughness of the surface, minimal groove errors, and higher peak efficiency than standard holographic gratings.

What is the commitment to quality for HORIBA Jobin Yvon's blazed holographic gratings?

HORIBA Jobin Yvon offers complete customer service, including expert technical advice for optimizing system configurations to meet customers’ needs. They are ISO9001:2000 certified, and their well-staffed departments are committed to customer satisfaction and product quality.

What substrate materials are available for blazed holographic gratings?

The standard substrate material is Pyrex, but on request, substrates including fused silica, Zerodur, ULE, metals, or other materials can be considered.

What coatings are available for blazed holographic gratings?

The standard coating is aluminum, but on request, AlMgF2, gold, or platinum are also available for an additional cost.

What applications are blazed holographic gratings suitable for?

Blazed holographic gratings are suitable for use in spectrometers, spectroscopy, and beam isolation.
