Description
Laser Output Couplers are optical components used to transmit a portion of the circulating intracavity power from a laser, generating a useful output beam. These couplers play a crucial role in laser performance, as their transmission level affects the laser threshold and efficiency.
By selecting the appropriate output coupler transmission, laser designers can optimize output power while considering other design requirements, such as minimizing intracavity intensities or suppressing Q-switching instabilities in mode-locked lasers.
EKSMA 031-0050 Laser Output Couplers
Specifications
| Substrate Material: | BK7 |
|---|---|
| Wavelength: | 1064 nm |
| Average Reflection: | 50 % |
| Average Transmission: | 50 % |
| Diameter: | 12.7 mm |
| Thickness: | 3 mm |
| Surface Flatness: | <= Lambda/10 |
| Surface Quality: | 20-10 scratch-dig |
| Transmission: | 85 % |
| Clear Aperture: | Exceeds central 85% of diameter |
| Parallelism: | 30 arcsec |
| Thickness Tolerance: | ±0.25 mm |
Download Data Sheet
Features
- Transmits a portion of intracavity power for useful output
- Affects laser threshold and efficiency
- Output coupler transmission can be optimized for maximum output power
- Available with different transmission levels to suit specific laser designs
- Enhances laser performance and beam quality
Applications
- Laser systems and devices
- Laser cutting and engraving machines
- Laser marking and welding systems
- Scientific and research lasers
- Medical and biomedical lasers
- Industrial and manufacturing lasers
Frequently Asked Questions
What is the optimum value of the output coupler transmission?
The optimum value of the output coupler transmission may be lower or higher if there are other design purposes (minimizing the intracavity intensities or suppressing Q-switching instabilities in a passively mode-locked laser).
What is the purpose of an output coupler?
The purpose of an output coupler is to transmit a part of the circulating intracavity power for generating a useful output from the laser.
What is the transmission of the output coupler?
The transmission of the output coupler is often chosen to maximize the achieved output power.
What is an output coupler?
An output coupler is a partially reflecting dielectric mirror used in a laser cavity.
What are the applications of an output coupler?
The applications of an output coupler are laser cavities.
