Description
The next product in Advanced Optowave’s ultra short-pulsed laser product line is the AOFemto™ Series. Like the AOPico™ Series, the AOFemto™ is also a diode-pumped solid-state Hybrid master-oscillator power-amplifier, the main difference is the addition of a compressor that enables the AOFemto™ to deliver pulse width less than 800 femtoseconds, with powers up to 15 watts in the IR and 7.5 watts in the green.
Our complete ultra short pulsed laser product line is built on a common platform, and we have designed it to use components that we also use in our nanosecond product line, components that have a solid track record for being highly reliable and stable. Because of the common components' utilization, we can provide you, the customer, with a much more cost-effective product.
Ultrashort pulse lasers have the unique ability to machine materials with little or no thermal damage, and the ability to machine materials that have not previously been able to be process with lasers.
AOFemto 1030nm 2W DPSS Laser
Specifications
| Avg. Power: | 2 W |
|---|---|
| Wavelength: | 1030 nm |
| Repetition Rate: | 1 – 100 kHz |
| Spatial Mode (M^2): | 1.3 |
| Pulse Duration: | 0.0008 ns |
| Pulse-to-Pulse Stability (RMS): | 2 % |
| Cooling: | Water-to-Water |
| Wavelength: | 1030 nm |
| Energy: | 20 µJ |
| Repetition Rate: | Single Shot to 1000 kHz |
| Beam Quality (M2): | <1.3 |
| Beam Roundness: | >85% |
| Beam Diameter: | 2.0 mm |
| Beam Divergence: | <1.3 mRad |
| Beam Divergence: | <0.7 mRad |
| Point Stability: | <20 µrad/ºC |
| Polarization Ratio: | 100:1 Linear, Vertical |
| Polarization Ratio: | 100:1 Linear, Horizontal |
| Pulse-to-Pulse Stability: | <2% RMS |
| Operational Temperature Range: | 15 to 30 ºC |
| Storage Temperature Range: | -20 to 50 ºC |
| Input Voltage: | 90 to 260 VAC |
Download Data Sheet
Features
- Lowest Cost of Ownership: Designed to provide the most economical solution in the industry.
- Excellent Beam Quality: Achieves a beam quality of M2 <1.3 for superior performance.
- Versatile Wavelength Options: Available in IR (1030 nm), Green (515 nm), and UV.
- High Average Power: Offers up to 15W average power for demanding applications.
- Ultra-Short Pulse Durations: Pulse durations of less than 800 fs for precision tasks.
- Highly Reliable Design: Engineered for consistent and dependable operation.
- Burst Mode Option: Provides flexibility for various micro-machining applications.
Applications
- Injector Drilling
- Medical Device Manufacturing
- Polymer Processing/Machining
- Semiconductor/PV Processing/Wafer Scribing
- High-Precision, High-Speed Micro-machining
- Brittle Material Cutting, Drilling, Dicing & Sub-Surface Marking
