Description
The Lightwave Receiver is a versatile and high-performance benchtop optical receiver, meticulously designed to meet the rigorous demands of high-speed testing in optical network systems and components. With its standard configuration, this receiver unit is capable of detecting modulation frequencies up to an impressive 11.5GHz bandwidth. This makes it an essential tool for professionals involved in the testing and development of optical communication systems.
At the heart of the Lightwave Receiver is a built-in low noise pre-amplifier EDFA, which provides the necessary pre-amplification of incoming signals before they reach the photoreceiver. This ensures that the signals are strong and clear, facilitating accurate testing and measurement. Additionally, the receiver includes an optical power monitor that allows for precise control of a variable optical attenuator, further enhancing its utility in various testing scenarios.
Manufactured under a HKQAA ISO 9001 certified quality management system, the Lightwave Receiver is a testament to quality and reliability. This certification, applicable to the Hong Kong production site, underscores the product's adherence to high manufacturing standards. For users requiring complete SONET system applications, an optional optical 10G clock recovery circuit can be integrated with the standard receiver unit, expanding its functionality and adaptability.
High-Speed Optical Receiver with Built-in Low Noise EDFA and Power Control
Specifications |
|
|---|---|
| Data Rate: | 155Mb/s to 11Gb/s |
| Input Power Level: | -12dBm to -3dBm |
| Optical Wavelength: | 1290nm to 1565nm |
| Maximum Optical Input Power: | 0dBm |
| Optical Power Measure Range: | -40dBm to 0dBm |
| Coupling: | AC –coupled to ground |
| Operation Temperature Range: | 0 to +40°C |
| Storage Temperature Range: | -10 to +70°C |
| Dimensions: | 350(W) x 300(L) x 100(H) mm |
| RF Data Input Connector: | SMA |
| Control: | EDFA driving current |
| Display: | EDFA laser output power, average input power |
| Optical Input Fiber: | SMF-28 |
Features
- Built-in Optical Power Control Module: Ensures precise management of optical power levels for optimal performance.
- Signal and Power Monitoring: Monitors incoming and amplified signal power for better control and diagnostics.
- Low Noise EDFA: Integrated low noise Erbium-Doped Fiber Amplifier enhances signal quality by pre-amplifying incoming signals.
- Wide-Frequency Bandwidth: Supports modulation frequencies up to 11.5GHz, accommodating high-speed data transmission.
- Broadband Wavelength Range: Operates across a wide optical wavelength range from 1290nm to 1565nm.
- Good Performance Cost Ratio: Offers excellent value for performance, making it a cost-effective solution for optical network testing.
- Two-Year Warranty: Provides peace of mind with a comprehensive two-year warranty.
Applications
- SONET/SDH Systems: Ideal for high-speed optical network component and system testing.
- CATV and 10G Ethernet: Suitable for broadband communication signal reception and analysis.
- Transmitter/Receiver Component Testing: Evaluates optical modules in R&D and production.
- Bit Error Rate Testing: Provides accurate BER testing for optical network systems.
Frequently Asked Questions
The Amonics Optical Receiver is designed for high speed testing of optical network systems and components.
The standard receiver unit can detect modulation frequency to 11.5GHz bandwidth.
The Amonics Optical Receiver has a built-in low noise pre-amp EDFA, an optical power monitor to control a variable optical attenuator, and a wide-frequency bandwidth.
The Amonics Optical Receiver is suitable for SONET/SDH Systems, CATV and 10G-Enet, Transmitter/Receiver components Testing, and Optical Network System Bit Error Rate Testing.
The Amonics Optical Receiver comes with a two year warranty.
