Lightwave Converter with DFB Laser and Variable Gain Control
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
China
-
Sold by:
-
On FindLight:
since 2014
Description
The Lightwave Converter is an advanced integrated lightwave transmitter designed to facilitate the development of both digital and analog optical transmission systems. This high-performance device combines a powerful laser with a broadband lithium niobate external modulator and a high-speed RF driver. This integration allows the Lightwave Converter to function seamlessly in various optical networks, whether in metropolitan areas or for long-haul transmission. Its versatility makes it an excellent choice for testing and other optical network applications.
Manufactured under a HKQAA ISO 9001 certified quality management system, the Lightwave Converter ensures high-quality standards and reliability. This certification applies specifically to the Hong Kong production site, underscoring the commitment to maintaining excellence in manufacturing processes. Customers can expect a robust product that meets rigorous industry standards, offering peace of mind and dependable performance.
The Lightwave Converter is not just about standard 10G conversion; it also supports higher-performance systems based on customer requirements. Options such as tunable wavelength lasers, RZ modulation, or even 40G bandwidth capabilities are available, making it a flexible solution for various optical transmission needs. With its cutting-edge technology and customizable options, the Lightwave Converter stands out as a superior choice for those seeking a reliable and efficient optical transmission solution.
Lightwave Converter with DFB Laser and Variable Gain Control
Specifications |
|
|---|---|
| Modulation Bandwidth: | 5kHz to 11GHz |
| Input RF Voltage: | > 0.5V peak to peak |
| RF S11 Return Loss: | > 10dB |
| Extinction: | > 20dB, 50MHz or under; > 13dB at 10GHz |
| Optical Input Power Handling: | < 500mW |
| Rise Time: | 38ps |
| Fall Time: | 40ps |
| Modulation Laser Output Power: | > 2mW |
| Operation Temperature Range: | 0 to +40 °C |
| Storage Temperature Range: | -10 to +70 °C |
| Dimensions: | 350(W) x300(L) x 100(H) mm |
Features
- Variable Driver Gain Control: Adjust the driver gain to suit different applications and requirements.
- Automatic and Manual Bias Control: Offers flexibility in controlling the bias for optimal performance.
- Built-in Stabilized DFB Laser: Ensures consistent and reliable laser output for high-quality transmission.
- Optional Built-in Tunable Laser: Provides additional flexibility for wavelength selection.
- Good Performance Cost Ratio: Delivers excellent performance without compromising on cost.
- Two Year Warranty: Offers peace of mind with a comprehensive warranty.
Applications
- SONET/SDH Systems: Ideal for integration in optical backbone networks for data transport.
- CATV and 10G Ethernet: Supports high-speed data transmission for broadband services.
- Remote RF Analog Links: Enables long-distance analog signal distribution with minimal loss.
- Laboratory Testing and Transponders: Suitable for optical component evaluation and transponder testing.
Frequently Asked Questions
The Lightwave Converter is a high performance integrated lightwave transmitter for building turnkey digital and analog optical transmission system.
The Lightwave Converter features variable driver gain control, automatic and manual bias control, built-in stabilized DFB laser, optional built-in tunable laser, good performance cost ratio, and a two-year warranty.
The Lightwave Converter can be used for SONET/SDH systems, CATV and 10G-Enet, remote RF analog link, laboratory testing and transponder, and evaluation.
The modulation bandwidth of the Lightwave Converter is 5kHz to 11GHz.
The Lightwave Converter comes with a two-year warranty.
