Description

The MicroMake Laser Micromachining System from Bright System is a cutting-edge solution for high-precision laser microprocessing tasks. This compact and integrated unit offers live imaging of processed samples during machining, enabling real-time quality assessment.

With the ability to ablate and cut programmable arbitrary shapes, it caters to a diverse range of applications such as precision surface texturing, microdrilling, and selective material removal. Equipped with both 532 nm and 266 nm lasers, it ensures versatility across various materials, from microelectronic circuits to biomedical devices and optical substrates. Featuring a standard 1 mm processing area and a spot size as small as 2 µm, it provides exceptional precision and resolution.

Optional features like different objective lenses, a high-speed USB camera, and an XYZ translation stage further enhance its capabilities. Compact in design and requiring low-voltage electrical power, the MicroMake system is ideal for OEM customers, while additional options can transform it into a comprehensive laser micromachining workstation, ready for a wide array of microfabrication tasks.

MicroMake 266: Laser Micromachining System

Specifications

Materials: Metals, Thermoset Plastics, Thermoplastics, Polimers, Textile, Wood, Paper, Stones, Ceramics, Glass
Laser Type: DPSS (Other)
Laser Wavelength: 266 nm (Deep UV)
Laser Output Power: 700 W
Laser Safety: Not classified
Work Area X: 1 mm
Work Area Y: 1 mm
Processing Speed: 2 mm/sec
Features And Options: Air-Cooled
Lens Magnification: 10x
Working Distance: 20 mm
Spatial Resolution: 2.5 µm
Frequency: 1 kHz
Overall Mechanical Dimensions: 39x20x11 cm3
Weight: 10 kg

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Ablation and cutting of programmable arbitrary shapes
  • Live imaging of processed samples during machining
  • Suitable for a wide range of materials
  • Down to 2 µm spot size
  • 532/266 nm ns and ps lasers
  • Embedded illumination unit
  • Optional XYZ translation stage

Applications

  • 3D direct microstructuring
  • Precision surface texturing
  • Track interruption on PCBs
  • Microcoding for anti-counterfeiting
  • Thin film removal on hard substrates
  • Selective metal removal on ceramic substrates
  • Microcorrection on wafers, masks, and displays
  • Microdrilling on metals and transparent dielectrics

Frequently Asked Questions

What is the MicroMake Laser Micromachining System?
The MicroMake Laser Micromachining System is an integrated and compact laser system designed for high-precision microprocessing tasks.
What applications is the MicroMake system suitable for?
The MicroMake system is suitable for a wide range of applications, including 3D direct microstructuring, precision surface texturing, microdrilling, selective material removal, and more.
What are the key features of the MicroMake system?
The MicroMake system offers live imaging of processed samples during machining, programmable arbitrary shape ablation and cutting, compatibility with 532 nm and 266 nm lasers, and a standard 1 mm processing area.
What optional features are available for the MicroMake system?
Optional features include different objective lenses, a high-speed USB camera, circular polarization on the workpiece, an external control box, and XYZ translation stages.
What materials can the MicroMake system work with?
The MicroMake system is suitable for working with a wide range of materials, including microelectronic circuits, biomedical devices, optical substrates, and various metals and transparent dielectrics.
Is the MicroMake system suitable for OEM customers?
Yes, the MicroMake system is designed with OEM customers in mind, offering compactness and single low-voltage electrical power requirements.
Where can I get more information about the MicroMake system?
For more information about the MicroMake system, you can contact Bright System via email at info@brightsystem.it or visit their website at www.brightsystem.it.

Got more questions? Use the inquiry form to ask the supplier directly.
