Description
The CO2 laser cutting machine is a powerful and versatile tool widely used in various industries for cutting and engraving materials. Known for its precision and efficiency, this machine has become an essential asset in manufacturing, design, and fabrication processes. This comprehensive guide will delve into the features, benefits, applications, and considerations for choosing a CO2 laser cutting machine.
CNC Laser Cutting Engraving Machine
Specifications |
|
|---|---|
| Format: | Benchtop |
| Laser Source: | CO2 |
| Laser Output Power: | 8 W |
| Laser Wavelength: | 10.6 um (IR) |
| Beam Delivery: | Flatbed |
| Work Area X: | 2500 mm |
| Work Area Y: | 1300 mm |
| Application: | Sheet Cutting |
| Sector: | Home Improvement, Hobby, Job Shop, Architecture |
| Materials: | Stainless Steel, Aluminum, Brass, Gold, Silver, Plastic, Wood |
| Voltage Requirement: | 110V - 60Hz, 220V - 50Hz |
| Safety Enclosure: | Not Specified |
| Laser Safety Class: | Other / Not Specified |
| Max Cutting Speed: | 5000 mm/s |
| Model: | iGL-B-1325 |
| Working Area: | 1300mm x 2500mm |
| Laser Power: | W2/W4/W6/W8 |
| Laser Type: | CO2 sealed laser tube, water-cooled |
| Cooling Way: | Water cooling CW3000/5000/5200 |
| Engraving Speed: | 0-60000 cm/min |
| Cutting Speed: | 0-30000 cm/min |
| Power Supply: | 220V/50Hz, 110V/60Hz |
| Laser Energy Control: | 1-100% software Settings |
| Graphic Format Supported: | BMP, PLT, DST, DXF, AI |
| Software Supported: | CorelDraw, Photoshop, AutoCAD, Tajima |
| Driving System: | 3-phase stepper motor with decelerator |
| Air Assist: | Air pump |
| Dichroic Cutting: | Yes |
| Optional Part: | Red light pointer |
Features
- Power: Laser cutting engraving machines come in different power options, ranging from lower power for acrylic and wood to higher power for metal cutting.
- Laser Type: There are two main types of lasers used in these machines – CO2 lasers and fiber lasers. CO2 lasers are suitable for acrylic and wood, while fiber lasers are more powerful and can cut through thicker metal materials.
- Precision and Accuracy: Laser cutting engraving machines offer high precision and accuracy, allowing for intricate designs and fine details.
- Versatility: These machines can work with a variety of materials, including acrylic, wood, and metal, making them suitable for a wide range of applications.
- Efficiency: Laser cutting engraving machines are efficient and can significantly reduce production time and labor costs. They have high cutting and engraving speeds, enabling faster project completion and increased productivity.
- Minimal Material Waste: The precision of laser cutting minimizes material waste by optimizing the cutting path and reducing kerf width, resulting in cost savings and a more sustainable production process.
- Non-Contact Process: Laser cutting and engraving are non-contact processes, eliminating the need for physical force or mechanical pressure on the material. This feature prevents potential damage to delicate or fragile materials.
Applications
A laser cutting engraving machine for acrylic, wood, and metal is a versatile tool that can be used for various applications. These machines utilize a laser beam to cut and engrave materials based on a pre-programmed design. Here are some features and applications of laser cutting engraving machines for acrylic, wood, and metal:
The laser cutting engraving machine is incredibly versatile, capable of working with various materials, including:
- Acrylic: Ideal for creating clear and colored acrylic signs, displays, and art pieces.
- Wood: Suitable for cutting and engraving wooden plaques, furniture, and decorative items.
- Metal: Can cut and engrave metals like steel, aluminum, and copper for industrial and artistic applications.
Frequently Asked Questions
The IGL-B1325 uses a CO2 sealed laser tube that is water-cooled.
The working area of the IGL-B1325 is 1300mm x 2500mm.
The IGL-B1325 can cut materials such as textile, fabric, cloth, jeans, leather, acrylic, wood, rubber, paper, and dual color board.
The engraving speed of the IGL-B1325 is 0-60000 cm/min.
The IGL-B1325 supports software such as CorelDraw, Photoshop, AutoCAD, and Tajima.
The laser energy control range is 1-100% and can be set through software.
The IGL-B1325 uses a 3-phase stepper motor with a decelerator for accurate positioning and high-speed cutting.
