L-EOS 1.7 Hyperspectral SWIR 900-1700 nm

Specifications

Sensor Type: InGaAs Array
# Pixels (Width): 512
# Pixels (Height): 640
Pixel Size (Square): 15 um
Peak Quantum Efficiency: 85 %
Full Frame Rate: 340 fps
Bit Depth: 14 bit
Spectral Range: 900-1700 nm
Sensor Type: InGaAs
Spatial Resolution: 6 pixels
Spectral Sampling: 1.3 nm/px
Document icon Download Data Sheet Download icon

Features


  • Scientific-Grade Precision: Benefit from low background noise, high dynamic range, and exceptional signal-to-noise ratios. Photon etc. L-EOS sets the bar for data quality, sensitivity, and resolution in infrared imaging.

  • Advanced Thermoelectric Cooling (TEC): Elevate your industrial processes with our cameras featuring 4 stages of thermoelectric cooling. Achieve temperatures as low as -60°C or -80°C, optimizing signal-to-noise ratios for precision applications.

  • Industrial-Ready Robustness: Dependable durability from Photon etc’s. L-EOS solutions. Our infrared cameras, objective telecentric lenses and precise spectrometers are engineered to meet industry standards, providing reliability in even the harshest industrial environments.

  • Versatile Applications: Spanning various industrial applications, from geology to material sorting and recycling, Photon etc.’s L-EOS is tailored to meet the unique demands of your industry with precision and reliability.


Elevate your industrial infrared imaging capabilities with Photon etc. L-EOS. Experience the perfect synergy of cutting-edge technology and industrial-grade robustness, empowering your applications with unmatched performance.

Applications


  • Material sorting (plastics and textiles): In the material sorting subsector, we optimize waste management with advanced optical sensors that detect and separate different types of materials based on their unique optical properties. This results in more efficient and accurate sorting of recyclable materials, reducing the amount of waste sent to landfill.

  • Hydrocarbon detection: In hydrocarbon detection, the use of infrared sensors and hyperspectral imager improves the detection and identification of hydrocarbons, allowing for monitoring of oil and gas leaks in pipelines and tanks, thereby enhancing safety and environmental protection.

  • Mining: In the mining subsector, we use photonic technology to improve mineral detection, enabling more precise exploration of mineral deposits and more efficient extraction of minerals. The combination of hyperspectral with other types of optical sensors (LIBS, XRF, LIF) can be used for precise geological analysis, reducing costs and waste in the extraction process.

  • Agricultural and agri-food markets: In the agricultural and agri-food markets, our optical sensors monitor crop quality and growth in real time. Infrared sensors can be used to monitor chlorophyll levels in plants with fluorescence allowing for monitoring of their health and growth.


Photon etc. is committed to advancing the industrial sector with our cutting-edge photonic solutions. Let us help you improve productivity, reduce costs, and enhance safety in your industry.
