Ascentta 1030 nm PM Fiber Circulator

Name: Ascentta Polarization Maintaining Fiber Circulator (1030nm)
Brand: Ascentta
SKU: FL-21770
Price: 1795.00 USD
Availability: InStock

Description

The compact and high-performance three-port fiber optic circulator from Ascentta, Inc. is a versatile optical device that enables simultaneous signal transmission from port 1 to port 2 and from port 2 to port 3.

Designed for use in DWDM systems with fiber gratings and other reflective components, this circulator delivers exceptional performance. Ascentta also offers multiport circulator modules with a maximum of N<=8 ports.

Specifications

Type Of The Device:	Circulator
Operating Wavelength:	1030 nm
Max Power:	0.25 W
Min Isolation:	22 dB
Insertion Loss (Fast Axis Block) (1→2, Or 2→3) Max.:	1.5 dB
Return Loss:	45 dB
Extinction Ratio:	20 dB
Directivity (1→3, Or 3→1) Min.:	40 dB
Operating Temperature:	+10 to +50 ℃
Storage Temperature:	0 to +60 °C
Manufacturer Part Number (MPN):	PMVCIR-3-1030-PM-L-10-FA
FindLight SKU:	FL-21770

Got questions about specs? Use the inquiry form to ask.

Download Data Sheet

Features

Compact and high-performance three-port fiber optic circulator
Simultaneous signal transmission from port 1 to port 2 and from port 2 to port 3
Ideal for DWDM systems with fiber gratings and reflective components

Applications

Fiber optic communication systems
Dense Wavelength Division Multiplexing (DWDM) systems
Fiber optic sensing and instrumentation
Optical signal routing and switching
Research and development in fiber optics

Export & Trade Information

ECCN:	EAR99
HTS Code:	9027.90.8400
Estimated US Tariff:	0%

Importing, tariffs & codes (Quick Guide) →

$1,795.00

Volume Pricing:

Qty	Unit Price	Extended Price
5	$1,785.00	$8,925.00
10	$1,775.00	$17,750.00

Discounts apply automatically in cart.

Shipping:: Arrange Pickup ⓘ
Ships from:: United States
Processing:: 40 days
Delivers to:: United States

Made by:: Ascentta
Made in:: China
Warranty:: View full terms
Returns:: View return policy
Sold by:: Ascentta
On FindLight:: since 2020

Got Questions? Ask Below ▼

Message the supplier directly
No signup or account needed
Expect a fast reply

Ask a Question

To: Ascentta
Re: Ascentta Polarization Maintaining Fiber Circulator (1030nm)

Name

Work Email

Organization

Country

Qty.

Your message to supplier

Thank you, your message was sent successfully.

Frequently Asked Questions

What are the wavelengths this product supports?

The product supports a range of wavelengths which include: 532nm, 635nm, 650nm, 780nm, 850nm, 980nm, 1030nm, and 1060nm. These values represent the operational wavelength range that the circulator can handle.

What is the transmitting direction of this product?

The product is designed to transmit in the direction from port 1 to port 2, and from port 2 to port 3. This indicates the sequence of ports in which the light circulates.

What is the typical and minimum isolation in dB?

The product provides a typical isolation of 23 dB for the wavelengths 532nm, 635nm, and 650nm, and 25 dB for 780nm and 850nm, and 27 dB for 980nm, 1030nm, and 1060nm. The minimum isolation is 20 dB for the wavelengths 532nm, 635nm, and 650nm, and 21 dB for 780nm and 850nm, and 22 dB for 980nm, 1030nm, and 1060nm. Isolation refers to the ability of the device to prevent light from returning to the source.
