100G QSFP28 Uplink 10Gb SFP+ 48 Port L3 Managed Fiber Switch

To: Zhengzhou Saga Telecom Co., Ltd.
Re: 100G QSFP28 Uplink 10Gb SFP+ 48 Port L3 Managed Fiber Switch

Description

The STH10G Series switches are designed based on new generations of domestic Switch Chips platform — BigFlow Series Chip platform

This series provide various power supply solutions for customers choosing, fixed single power supply, fixed redundant power supplies, and redundant hot-swappable power supplies (AC and DC are both available).

The Fan solutions also have multiple bays with Field replaceable fan modules and build in fans. Generally, air flow of STH10G Series is front to rear (AFO), and some of models can do a customization of rear to front (AFI) airflow.

Specifications

Model Name:	STH-8C48XF-HSI
Port:	8100G QSFP28 and 4810G SFP+
Power:	Optional AC/DC Input, Plug and Play
Airflow:	Front to Rear
Fan:	2*hot-swappable fan modulars
Features:	IPv6, OSPF, BGP, PIM, MPLS, Stacking etc.
Chip:	CENTEC CTC8180
Customization:	Support
Dimension:	44235644mm
Weight:	8.5Kg/N.W, 12Kg/G.W
Warranty:	1 Year

Download Data Sheet

Features

Support MPLS features (L2/L3 VPN) to build a unified and converged network platform.
MLAG which can build an Active-Active system to improve the reliability of the network links from single board grade to device grade.
Implementing Vxlan and BGP protocols to build EVPN applications for data centers scenario.
Switch-to-switch encryption using MACsec (Media Access Control Security) AES-CMAC.
Precision Timing Protocol.
Rich L2/L3 features like IPv6, OSPF, BGP, PIM, etc.
