S7075xM 7-Port 10/100 Managed Switch
Description
The S7075xM 7-port switch performs all of the operations of our 5 port switch with two 10/100 Fast Ethernet ports added. If you need a web smart managed version with 6 UTP ports and 1 fiber port that can be used with 10 base or 100base networks, this product may be a good choice for you. With comprehensive LED's, ST or SC connector options, auto-negotiation, and store and forward switching, the S7075xM is a winner for those who need to keep up with an ever evolving network.
S7075xM 7-Port 10/100 Managed Switch
Specifications |
|
|---|---|
| Number Of Ports: | 1-7 |
| Wavelength Range: | 1000-1600nm |
| Insertion Loss (typical): | - dB |
| Return Loss: | - dB |
Features
Complies with IEEE 802.3 10Base-T, 802.3u 100Base-TX, 100Base-FX standards
Provides 6 10/100 Fast Ethernet ports and 1 100Base-FX port
Each TP port supports auto-negotiation and auto-MDI/MDI-X detection
Supports full/half duplex operation for each TP switched port
Supports ST or SC fiber connectors
Multimode and singlemode fiber cables (model dependent)
Self learning for active MAC addresses up to 2K entries
Store-and-forward switching so only good packets are forwarded
Forwarding and filtering at full wire speed
Flow control for traffic congestion
Broadcast packet storm protection
Comprehensive LED indicators
