LightShift
Description
Snapshot spectral imagers are systems in which the entire spectral dataset is obtained during a single detector integration period and thus have a distinct advantage in spectral imaging of fast changing phenomena. The amount of information generated by even snapshot systems is still a key challenge since their application to many practical tasks depends on the ability to process the substantial volume amount of data and make decisions on it in real time. The snapshot spectral imager must process at rates keeping pace with the real-time acquisition of images. LVIRA process the images spectrally in real time, from initial gain and offset compensation and spectroradiometric calibration through decision oriented processing, including spectral correlation using varied algorithms. LightShift™ is the first commercial multimodal snapshot spectral and polarization imager with video-rate acquisition and processing. Simultaneously capture spectral, light field and polarization information for every pixel. Separately these dimensions provide a partial representation of the scene. LightShift joins them to achieve better classification performance and provides researchers with new functionality for viewing targeted objects.
LightShift
Specifications |
|
|---|---|
| Imaging Mode: | Photoluminescence (PL) |
| Excitation Wavelength: | Custom |
| Spectral Range (Raman Imaging): | Custom |
| Spectral Range (PL, EL, DR Imaging): | 400 - 1000 nm |
| Spectral Resolution (Raman Imaging): | Custom |
| Spectral Resolution (PL, EL, DR Imaging): | Custom |
| Spatial Resolution: | Nanometer Range |
Features
Spectral
Material Composition
Polarized Light
Surface Characteristics
Light Field
Viewpoint Diversity and Depth
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
External Vendor
Claim Surface Optics Corp Page to edit and add data
Frequently Asked Questions
LightShift features simultaneous capture of spectral, light field, and polarization information for every pixel, snapshot acquisition and processing, and customization with 16 bandpass filters or polarizers specific to your application's region of interest.
Light field imaging can render depth estimation, scene recovery, digital refocusing, and dynamic depth-of-field.
LightShift is a commercial multimodal snapshot spectral and polarization imager with video-rate acquisition and processing.
Snapshot spectral imagers have the advantage of obtaining the entire spectral dataset during a single detector integration period, making them ideal for dynamic scene applications.
Polarization information can find surface properties of an object such as diffuse or specular reflection, scattering, and refractive index, enhancing the discriminating power of vision-based detection and classification systems.
