Description
The SOC710 Series Hyperspectral Imaging Systems represent a groundbreaking advancement in the field of hyperspectral imaging. Designed to eliminate the need for cumbersome scanning stages during both laboratory and field research, the SOC710 Series offers high spectral resolution in a compact and portable form. This user-friendly design is tailored to meet the needs of researchers who require precision and flexibility without the burden of additional hardware.
One of the standout features of the SOC710 Series is its internal scanning mechanism, which sets it apart from traditional line scanning systems. Unlike conventional "push broom" systems that require a translation stage to move samples in front of the camera, the SOC710-VP allows the sensor to move behind the lens. This innovative design integrates the scanning speed and translation rate with the system's exposure and gain parameters, simplifying the process for the operator and ensuring optimal results without manual calculations.
The portability of the SOC710-VP is unmatched, making it an ideal choice for in-situ field data collection. Its small footprint and absence of external stage hardware provide unparalleled versatility, allowing researchers to conduct varied experimental setups with ease. Whether in the lab or the field, the SOC710 Series offers the flexibility needed for a wide range of applications, from environmental monitoring to defense and security.
The SOC710 Series is not only about cutting-edge technology but also about supporting researchers in their endeavors. With excellent post-sale support and compatibility with third-party analysis software such as ENVI or MATLAB, the SOC710 Series ensures that users have the resources they need to succeed. This commitment to customer satisfaction makes the SOC710 Series a trusted partner in the pursuit of scientific discovery.
710-VP Hyperspectral Imaging System
Specifications |
|
|---|---|
| Imaging Mode: | Electroluminescence (EL), Raman, Photoluminescence (PL), Diffuse Reflectance (DR) |
| Excitation Wavelength: | Custom |
| Spectral Range (Raman Imaging): | Custom |
| Spectral Range (PL, EL, DR Imaging): | 400 - 1000 nm |
| Spectral Resolution (Raman Imaging): | Custom |
| Spectral Resolution (PL, EL, DR Imaging): | <5 nm |
| Spatial Resolution: | Nanometer Range |
Features
- Eliminates Need for Translation Stage: The SOC710 Series removes the necessity for scanning stages during lab and field research, offering a streamlined process.
- Live Video Preview: Equipped with a preview camera that provides live video for scene framing and focusing, ensuring precise data capture.
- High Dynamic Range Experiments: The precision scanning mechanism of the 710-VP allows for high dynamic range experiments with two scans of the same scene at different gain settings.
- Versatile Scanning Modes: Operate in traditional line scanning or internal scanning modes, easily switching between acquisition modes with a simple software toggle.
- Open Format Data: Data is recorded in an open format binary compatible with third-party analysis software such as ENVI or MATLAB, facilitating easy integration into existing workflows.
- Portable and Flexible Design: The SOC710-VP’s small footprint and lack of external stage hardware make it highly portable, ideal for in-situ field data collection.
- Excellent Post-Sale Support: Benefit from comprehensive support to ensure optimal use and maintenance of the system.
Applications
- Food Processing: Enables precise spectral analysis for quality control and safety monitoring.
- Agriculture: Provides crop health, soil condition, and vegetation analysis with high spectral accuracy.
- Forensics: Supports detailed material and chemical identification for investigative applications.
- Medicine & Biology: Facilitates tissue characterization, medical imaging, and biological studies.
- Defense & Security: Enhances surveillance, camouflage detection, and material identification.
- Environmental Monitoring: Detects pollutants, assesses ecosystems, and supports field-based research.
- Machine Vision & Color Analysis: Improves industrial sorting, inspection, and quality assurance processes.
Frequently Asked Questions
Yes, the SOC710-VP Hyperspectral Imaging System can be operated in traditional line scanning or internal scanning modes. The acquisition modes can be switched with a simple software toggle.
The SOC710-VP Hyperspectral Imaging System is suitable for various applications such as food processing, agriculture, microscopy, forensics, ground truth, medicine, biology, defense & security, machine vision, color analysis, environmental monitoring, and chemometrics.
The SOC710-VP Hyperspectral Imaging System features a preview camera that provides live video for scene framing and focusing, a precision scanning mechanism that allows for high dynamic range experiments with two scans of the same scene at different gain settings, and excellent post-sale support. It can be operated in traditional line scanning or internal scanning modes and data recorded in open format binary compatible with third-party analysis software such as ENVI or MATLAB.
Traditional line scanning hyperspectral imaging systems require a translation stage to move target samples in front of the camera, which necessitates multiple stages or additional hardware to perform varied lab and field experimental setups. With the SOC710-VP, the sensor moves behind the lens and the scanning speed or translation rate is intimately tied into the exposure and gain parameters of the system, eliminating the need for external stage hardware.
The SOC710-VP Hyperspectral Imaging System is a compact and portable imaging system that eliminates the need for translation stage or sample stage during lab and field research.
