GZT-009006 series Rigid Optical Vibration Isolation Test Table

Specifications

Table Material: Custom
Hole Pattern: Not Specified
Table Length: 900 mm
Table Width: 900 mm
Table Thickness: 500 mm
Flatness: Not Specified
Document icon Download Data Sheet Download icon

Features


  • Ultra-Thin Air Spring Isolation: Equipped with an innovative ultra-thin air spring structure, the table ensures effective vibration isolation, making it suitable for even the most sensitive optical and laboratory setups.

  • Porous Quasi-Laminar Flow Damping: The table features a porous quasi-laminar flow damping element, which diffuses vibration energy for superior damping performance and ensures minimal interference during critical operations.

  • Manual Leveling Adjustment: The table allows for precise manual leveling with an accuracy of ±0.1mm, ensuring that your equipment remains perfectly balanced, even during long experimental runs.

  • Silent Compressor: Operating with a silent compressor that generates less than 50dB of noise, the table ensures a quiet working environment, reducing distractions during experiments.

  • Customizable Design: With OEM support and a customizable brand name, this optical table can be tailored to meet your specific branding and functional requirements.

Applications

The GZT-009006 Series Optical Table is designed for a variety of high-precision applications that require stable, vibration-free environments. Its advanced isolation and damping technologies make it ideal for the following fields:



  • Optical Experiments:
    Perfect for laser alignment, interferometry, spectroscopy, and other experiments that require a stable surface for precise optical instrumentation. The ultra-thin air spring vibration isolation ensures minimal disruption to sensitive measurements.

  • Microscopy and Imaging:
    Widely used in electron microscopy, confocal microscopy, and other high-resolution imaging techniques. The table’s high flatness (≤0.05mm/m²) and low surface roughness (≤0.8μm) ensure that imaging systems remain stable, enhancing image quality and reducing drift.

  • Photonics and Fiber Optics:
    Suitable for photonics research, fiber optic experiments, and waveguide testing. The table's advanced damping system minimizes environmental vibrations, which is crucial for experiments involving delicate optical components or fine alignment.

  • Precision Metrology:
    Ideal for precise measurement instruments, such as coordinate measuring machines (CMMs) and profilometers. The high accuracy of leveling (±0.1mm) and manual adjustment capabilities help maintain the integrity of fine measurements.

  • Quantum Research:
    Quantum optics and quantum computing setups benefit from the table's ultra-stable environment. The table’s silent compressor and low-noise operation (<50dB) help minimize external interference, crucial for delicate quantum systems.
    Semiconductor Testing and Manufacturing:
    Useful in semiconductor wafer testing, lithography, and other precision manufacturing processes where vibration isolation is necessary to maintain process quality and accuracy.

  • Medical and Biological Research:
    Used in laboratories conducting biological research, such as live-cell imaging, neuroscience, or drug testing, where eliminating vibrations can reduce measurement errors and improve data reliability.

  • High-Sensitivity Instrumentation:
    Any application that uses atomic force microscopes (AFMs), scanning tunneling microscopes (STMs), or other high-sensitivity equipment benefits from the table’s precision surface and vibration isolation capabilities.
