Description
Dove prism is always used to rotate image. If you rotate the prism around a longitudinal axis, the image rotates through twice the angle the prism rotates through. Sometimes, dove prism is also used for 180deg reflection
Union Optic Dove Prism
Specifications
| Material: | BK7, UVFS |
|---|---|
| Dimension (A): | 21.1 mm |
| Dimension (B): | 5 mm |
| Dimension (h): | 5 mm |
| Mounting: | Unmounted |
Download Data Sheet
Features
Dimension Tolerance ±0.2mm
Surface Quality 60/40 scratch and dig
Flatness λ/4@632.8nm
Clear Aperture >90%
Angle Tolerance <3 arc minutes
Chamfer Protective chamfer
AR Coating No, Available
Frequently Asked Questions
What is the angle tolerance of the dove prism?
The angle tolerance of the dove prism is less than 3 arc minutes.
What is the surface quality of the prism?
The surface quality of the prism is 60/40 scratch and dig.
How much does the dove prism deviate the light beam?
The dove prism deviates the light beam by 90 degrees.
Is there an AR coating available for the dove prism?
Yes, an AR coating is available for the dove prism.
What is a dove prism used for?
A dove prism is used to rotate an image.
