BK7 Grade A Optical Glass Standard MB11-038 Circular Mirror
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2015
Description
At Tower Optical, we pride ourselves on offering mirrors with a highly polished surface designed for optimal light reflection. These mirrors are crafted with a thin coating of aluminum or silver, ensuring superior reflectivity. Our mirrors are predominantly first surface types, meaning the reflective coating is applied to the front surface. This design choice eliminates any interference from the glass itself, ensuring that the incident and reflected light maintain their intended optical properties. The rear surface of our mirrors is finely ground to enhance their overall quality.
All our mirrors feature a protected aluminum coating on the front surface, ensuring durability and longevity. We offer two grades of mirrors: Standard Grade and High Grade. Both grades are made from BK7 grade A optical glass, with the High Grade also available in UV Grade Fused Silica for specialized applications. Our commitment to quality is evident in the precise dimensional tolerances and exceptional surface quality of our products. Each mirror is crafted to meet stringent flatness and parallelism standards, ensuring they perform flawlessly in any optical application.
We understand that every project is unique, which is why we offer custom versions of all our mirrors. Whether you require specific dimensions or have particular specifications in mind, our team is ready to assist. Simply send us your drawings or specifications, and we will provide a detailed quotation tailored to your needs. At Tower Optical, quality is not just a promise; it is a priceless commitment to excellence.
BK7 Grade A Optical Glass Standard MB11-038 Circular Mirror
Specifications |
|
|---|---|
| Reflective Coating: | Protected Silver, Protected Aluminum |
| Substrate: | BK7 |
| Average Reflectance: | 95 % |
| Wavelength Range: | 500 – 1000 nm |
| Surface Flatness: | lambda/6 |
| Surface Quality: | 40-20 scratch-dig |
| Diameter: | 38 mm |
| Thickness: | 4 mm |
| Shape: | Round, Square |
Features
- High-Quality Reflective Surface: Our mirrors feature a highly polished surface with a thin coating of aluminum or silver, ensuring optimal light reflection.
- First Surface Mirrors: Designed for optical applications, these mirrors have the reflective coating on the front surface to eliminate the optical properties of the glass from affecting light.
- Protected Aluminum Coating: All mirrors come with a protected aluminum coating applied to the front surface for enhanced durability and performance.
- Material Options: Available in BK7 Grade A optical glass and UV Grade Fused Silica for different application needs.
- Dimensional Precision: Both standard and high-grade mirrors offer a dimensional tolerance of +0.0/-0.1mm, ensuring precise fit and function.
- Surface Flatness: Standard grade mirrors have a flatness of λ/5 @ 632.8nm, while high-grade mirrors offer superior flatness at λ/10 @ 632.8nm.
- Surface Quality: The mirrors feature excellent surface quality with scratch/dig specifications of 40/20 for standard grade and 10/5 for high-grade mirrors.
- Thickness Tolerance: All mirrors maintain a thickness tolerance of ±0.2mm for consistent performance.
- Parallelism: Ensures high precision with parallelism of less than 3 arc minutes.
- Custom Options Available: We offer custom versions of all products. Send us your drawings or specifications for a personalized quotation.
Applications
- Laser Systems: Ideal for beam steering, alignment, and reflection.
- Optical Instruments: Used in interferometers, spectrometers, and imaging systems.
- R&D Laboratories: Reliable mirrors for scientific experiments and prototype development.
- Medical & Industrial Equipment: Supports applications requiring precise beam control.
- Custom Optical Assemblies: Flexible integration into specialized optical systems.
Frequently Asked Questions
The purpose of a circular mirror is to reflect light.
The reflecting surface of the mirror is usually a thin coating of aluminum or silver.
A first surface mirror is a mirror where the coating is on the front surface, thereby eliminating the optical properties of the glass from affecting the incident or reflected light.
The thickness tolerance of the mirrors is ±0.2mm.
The surface quality of the mirrors is scratch/dig 40/20 or 10/5.
