Blazed Holographic Grating 530 13
Description
HORIBA Jobin Yvon has produced a wide range of blazed holographic master gratings from which we manufacture high precision replicas.
Our replica gratings retain the advantages of our master holographic gratings:
❏ Perfect periodicity, plus excellent micro-roughness of the surface eliminates ghosts and enhances stray light rejection
❏ Minimal groove errors provide very high resolution
In addition, owing to their ion-etched, sawtooth groove profiles, these gratings offer higher peak efficiency than standard holographic gratings.
Blazed Holographic Grating 530 13
Specifications |
|
|---|---|
| Groove Density: | 2400 l/mm |
| Spectral Range: | 190-700nm |
| Blaze: | Blazed |
| Blaze Wavelength: | 250 nm |
| Dimension (Length): | 120 mm |
| Dimension (Height): | 140 mm |
| Dimension (Thickness): | 20 mm |
| Substrate Material: | Fused Silica, NBK7, Pyrex, Zerodur, ULE, Metallic, Custom |
Features
Standard substrate material is Pyrex; on request, substrates including fused silica, Zerodur, ULE, metals, or other materials can be considered. Standard coating is aluminium. On request, AlMgF2, gold or platinum are also available for an additional cost.
Applications
Spectrometers
Spectroscopy
Beam isolation
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
United States
-
Sold by:
-
On FindLight:
since 2016
Frequently Asked Questions
Blazed holographic gratings are high precision replicas of master holographic gratings produced by HORIBA Jobin Yvon. They offer perfect periodicity, minimal groove errors, and excellent micro-roughness of the surface, which eliminates ghosts and enhances stray light rejection.
HORIBA Jobin Yvon is ISO9001:2000 certified and offers complete customer service, including expert technical advice for optimizing system configurations to meet customers’ needs. The company is committed to customer satisfaction and product quality.
The standard substrate material is Pyrex, but on request, substrates including fused silica, Zerodur, ULE, metals, or other materials can be considered.
The standard coating is aluminum, but on request, AlMgF2, gold, or platinum are also available for an additional cost.
Blazed holographic gratings are suitable for use in spectrometers, spectroscopy, and beam isolation.
