Page 4 - Modulated Fiber-Coupled Diode Lasers >> Suppliers | Specifications

QPhotonics LLC

Add to watch list

QFLD-405-20S Fiber-Coupled Laser Diode

Specifications
Laser Type:	Continuous Wave (CW), Modulated, Pulsed
Fiber Type:	Single Mode
Wavelength:	406 nm
Output Power:	20 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

QFLD-405-10SAX Fiber-Coupled Laser Diode

QPhotonics LLC

Add to watch list

QFLD-405-10SAX Fiber-Coupled Diode

Specifications
Laser Type:	Continuous Wave (CW), Modulated, Pulsed
Fiber Type:	Single Mode
Wavelength:	404 nm
Output Power:	10.4 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

Customized Fiber-Coupled Laser Source Model QTFS-405-LD/LD-04-410

QPhotonics LLC

Add to watch list

Customized Fiber-Coupled Laser Source Model: QTFS-405-LD/LD-04-410

Specifications
Laser Type:	Continuous Wave (CW), Modulated, Pulsed
Fiber Type:	Multi-Mode
Wavelength:	410 nm
Output Power:	50 mW
Fiber Core Diamater:	62.5 um
...

Data Sheet

EP2330-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP2330-0-DM series is designed for Carbon Monoxidedetection using the 2330 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 2330 nm for a wide range of Carbon Monoxide detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	2330 nm
Output Power:	1 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP2051-0-DMH SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP2051-0-DMH, part of our high powered laser series, is designed for Carbon Dioxide detection using the 2051 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 2051 nm for a wide range of CO2 detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	2051 nm
Output Power:	10 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP2051-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP2051-0-DM series is designed for Carbon Dioxide detection using the 2051 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 2051 nm for a wide range of Carbon Dioxide detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	2051 nm
Output Power:	1 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP2004-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP2004-0-DM series is designed for CO2 detection using the 2004 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform, delivering incredibly stable, precise lasing performance at 2004 nm for a range of Carbon Dioxide detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	2004 nm
Output Power:	2 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1950-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP1950-0-DM series is designed for seeding of Thulium doped fiber amplifiers and lasers, as well as various sensing applications. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 1950 nm.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1950 nm
Output Power:	1 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1877-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP1877-0-DM laser series delivers Single Mode emission in the 1.88 μm region for applications such as moisture detection using the 1877 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 1877 nm for a wide range ...

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1877 nm
Output Power:	2 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1742-2-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP1742-2-DM series is designed for Hydrogen Chloride detection using the 1742 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 1742 nm for a wide range of hydrogen chloride detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1742 nm
Output Power:	5 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1692-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP1692-0-DM series is designed for hydrocarbon detection using the 1692.5 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 1692 nm for a wide range of hydrocarbon detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1692 nm
Output Power:	6 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1653-7-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP1653-7-DM series is designed for methane detection using the 1653.7 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 1653.7 nm for a wide range of methane detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1653.7 nm
Output Power:	5 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1550-0-NLW-400 kHz SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s NLW series has become the industry standard in monolithic, ultra narrow linewidth laser diodes in the near infrared. Built on Eblana\'s Discrete Mode technology platform these lasers are the ultimate solution where the highest spectral purity must be delivered in the harshest environmental conditions.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1550 nm
Output Power:	5 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1550-0-NLW-100 kHz SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s NLW series has become the industry standard in monolithic, ultra narrow linewidth laser diodes in the near infrared. Built on Eblana\'s Discrete Mode technology platform these lasers are the ultimate solution where the highest spectral purity must be delivered in the harshest environmental conditions.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1550 nm
Output Power:	5 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1512-2-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP1512-2-DM series is designed for ammonia detection using the 1512 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 1512 nm for a wide range of ammonia detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1512 nm
Output Power:	10 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1392-5-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP1392-5-DM series is designed for moisture detection using the 1392.5 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 1392.5 nm for a wide range of moisture detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1392.5 nm
Output Power:	10 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP1278-1-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP1278-1-DM series is designed for Hydrogen Fluoridedetection using the 1278.1 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 1278 nm for a wide range of Hydrogen Fluoride detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1278.1 nm
Output Power:	8 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP780-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP780-0-DM series is designed for Rubidium detection using the 780 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 780 nm for a wide range of Rubidium detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	780 nm
Output Power:	12 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP760-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP760-0-DM series is designed for Oxygen detection using the 760 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 760 nm for a wide range of Oxygen detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	760 nm
Output Power:	10 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

EP689-0-DM SERIES

Eblana Photonics Ltd.

Add to watch list

Eblana\'s EP689-0-DM series is designed for Strontium detection using the 689 nm absorption line. This laser is built on Eblana\'s Discrete Mode technology platform and delivers stable, precise lasing performance at 689 nm for a wide range of Strontium detection applications.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	689 nm
Output Power:	10 mW
Fiber Core Diamater:	N/A um
...

Data Sheet

1550nm 62.5 µm MMF DFB And Fabry-Perot Laser

Bola Technologies

Add to watch list

The Bench Top Optical Source series is an intelligent, high-function stable light source. By utilizing the highly functional automatic power control and auto temperature control technologies, the series has guaranteed output power stability. The Bola Optical Source is available in Rack Mount and Bench Top cabinets.

Specifications
Laser Type:	Modulated
Fiber Type:	Multi-Mode
Wavelength:	1550 nm
Output Power:	N/A mW
Fiber Core Diamater:	62.5 um
...

Data Sheet

1550nm 50 µm MMF DFB And Fabry-Perot Laser

Bola Technologies

Add to watch list

The Bench Top Optical Source series is an intelligent, high-function stable light source. By utilizing the highly functional automatic power control and auto temperature control technologies, the series has guaranteed output power stability. The Bola Optical Source is available in Rack Mount and Bench Top cabinets.

Specifications
Laser Type:	Modulated
Fiber Type:	Multi-Mode
Wavelength:	1550 nm
Output Power:	N/A mW
Fiber Core Diamater:	50 um
...

Data Sheet

1550nm 9 µm SMF DFB And Fabry-Perot Laser

Bola Technologies

Add to watch list

The Bench Top Optical Source series is an intelligent, high-function stable light source. By utilizing the highly functional automatic power control and auto temperature control technologies, the series has guaranteed output power stability. The Bola Optical Source is available in Rack Mount and Bench Top cabinets.

Specifications
Laser Type:	Modulated
Fiber Type:	Single Mode
Wavelength:	1550 nm
Output Power:	N/A mW
Fiber Core Diamater:	9 um
...

Data Sheet

1480nm 62.5 µm MMF DFB And Fabry-Perot Laser

Bola Technologies

Add to watch list

The Bench Top Optical Source series is an intelligent, high-function stable light source. By utilizing the highly functional automatic power control and auto temperature control technologies, the series has guaranteed output power stability. The Bola Optical Source is available in Rack Mount and Bench Top cabinets.

Specifications
Laser Type:	Modulated
Fiber Type:	Multi-Mode
Wavelength:	1480 nm
Output Power:	N/A mW
Fiber Core Diamater:	62.5 um
...

Data Sheet

1480nm 50 µm MMF DFB And Fabry-Perot Laser

Bola Technologies

Add to watch list

The Bench Top Optical Source series is an intelligent, high-function stable light source. By utilizing the highly functional automatic power control and auto temperature control technologies, the series has guaranteed output power stability. The Bola Optical Source is available in Rack Mount and Bench Top cabinets.

Specifications
Laser Type:	Modulated
Fiber Type:	Multi-Mode
Wavelength:	1480 nm
Output Power:	N/A mW
Fiber Core Diamater:	50 um
...

Data Sheet
