LumiBrightTM FC 2400B-510
Innovations in Optics
The Model FC 2400B-510 is designed for high luminous flux, white LED illumination into optical fibers, bundles and light guides sized from 1.0 to 3.0mm in diameter. The product features patented technologies that encompass non-imaging optics with chip-on-board metallic substrates to provide both optimum luminous efficacy as well as ...
  • LED Color: White
  • Wavelength Range: 400 - 720 nm
  • Output Power (CW): 510 W
  • Emission Angle (Divergence): -- deg
  • Numerical Aperture (NA): 0.66
Data Sheet
LumiBrightTM LE 2400B-400-W
Innovations in Optics
The Model 2400B-400-W is a light engine providing high luminous flux, white LED illumination into optical fibers, bundles and light guides sized from 6.0 to 8.0 mm in diameter. The product features patented technologiesthat encompass non-imaging optics with chip-on-board metallic substrates to provide both optimum luminous efficacy ...
  • LED Color: White
  • Wavelength Range: 400 - 720 nm
  • Output Power (CW): 400 W
  • Emission Angle (Divergence): -- deg
  • Numerical Aperture (NA): 0.66
Data Sheet
LumiBrightTM LE 2400B-500-W
Innovations in Optics
The Model 2400B-500-W is a light engine providing high luminous flux, white LED illumination into optical fibers, bundles and light guides sized from 3.0 to 5.0 mm in diameter. The product features patented technologiesthat encompass non-imaging optics with chip-on-board metallic substrates to provide both optimum luminous efficacy ...
  • LED Color: White
  • Wavelength Range: 400 - 720 nm
  • Output Power (CW): 500 W
  • Emission Angle (Divergence): -- deg
  • Numerical Aperture (NA): 0.60
Data Sheet
LumiBrightTM LE 2600N-100
Innovations in Optics
LumiBright LE Light Engines provide extreme brightness and a highly uniform light distribution. Chip-on-Board LED technology with metallic PCB substrates offers excellent thermal performance. The patented primary optic is a non-imaging concentrator that delivers high collection efficiency and a homogeneous beam requiring no ...
  • LED Color: Red, Green, Blue, Near Infrared (NIR)
  • Wavelength Range: 470 - 1720 nm
  • Output Power (CW): 0.491 W
  • Emission Angle (Divergence): 20 deg
Data Sheet
LumiBrightTM LE 2400B-300
Innovations in Optics
LumiBright LE Light Engines provide extreme brightness and a highly uniform light distribution. Chip-on-Board LED technology with metallic PCB substrates offers excellent thermal performance. The patented primary optic is a non-imaging concentrator that delivers high collection efficiency and a homogeneous beam requiring no ...
  • LED Color: Red, Green, Blue, Near Infrared (NIR)
  • Wavelength Range: 470 - 1720 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 37 deg
Data Sheet
LumiBrightTM LE 2400B-100
Innovations in Optics
LumiBright LE Light Engines provide extreme brightness and a highly uniform light distribution. Chip-on-Board LED technology with metallic PCB substrates offers excellent thermal performance. The patented primary optic is a non-imaging concentrator that delivers high collection efficiency and a homogeneous beam requiring no ...
  • LED Color: Red, Green, Blue
  • Wavelength Range: 470 - 1720 nm
  • Output Power (CW): 0.491 W
  • Emission Angle (Divergence): 41 deg
Data Sheet
LumiBrightTM UV LED 1700A-100
Innovations in Optics
The versatile and powerful UV LumiBright Fiber Coupled devices are ideal for fiber optic applications in industrial, medical, and laboratory equipment. The couplers incorporate LumiBright Light Engines with interfaces for light guides or fiber bundles. Chip-on-Board LED technology with metallic PCB substrates offers excellent thermal ...
  • LED Color: Ultraviolet (UV)
  • Wavelength Range: 365 - 405 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): -- deg
Data Sheet
LumiBrightTM UV 2600N-705
Innovations in Optics
LumiBright Ultraviolet Light Engines provide extreme brightness and a highly uniform light distribution. Chip-on-Board LED technology with metallic PCB substrates offers excellent thermal performance. The specialized glass primaryoptic is ideal for high power UV light. It is a non-imaging concentrator that delivers high collection ...
  • LED Color: Ultraviolet (UV)
  • Wavelength Range: 350 - 450 nm
  • Output Power (CW): 30 W
  • Emission Angle (Divergence): 20 deg
  • UV Optical Power Density: 20 W/cm2
Data Sheet
LumiBrightTM UV 2400B-405
Innovations in Optics
LumiBright Ultraviolet Light Engines provide extreme brightness and a highly uniform light distribution. Chip-on-Board LED technology with metallic PCB substrates offers excellent thermal performance. The specialized glass primaryoptic is ideal for high power UV light. It is a non-imaging concentrator that delivers high collection ...
  • LED Color: Ultraviolet (UV)
  • Wavelength Range: 350 - 450 nm
  • Output Power (CW): 30 W
  • Emission Angle (Divergence): 41 deg
  • UV Optical Power Density: 70 W/cm2
Data Sheet
LumiBrightTM UV 2400B-505
Innovations in Optics
LumiBright Ultraviolet Light Engines provide extreme brightness and a highly uniform light distribution. Chip-on-Board LED technology with metallic PCB substrates offers excellent thermal performance. The specialized glass primaryoptic is ideal for high power UV light. It is a non-imaging concentrator that delivers high collection ...
  • LED Color: Ultraviolet (UV)
  • Wavelength Range: 350 - 450 nm
  • Output Power (CW): 90 W
  • Emission Angle (Divergence): 37 deg
  • UV Optical Power Density: 95 W/cm2
Data Sheet
Cree XLamp CMT1930 LED
Cree
The XLamp® High Current LED Array family is optimized for best-in-class lumen output, efficacy and reliability at high drive currents. XLamp CMT LEDs deliver the best performance and metal COB reliability in industry-compatible footprints and LES sizes, enabling lighting manufacturers to upgrade their designs for applications such as ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 115 deg
Data Sheet
Cree XLamp CMT1945 LED
Cree
The XLamp® High Current LED Array family is optimized for best-in-class lumen output, efficacy and reliability at high drive currents. XLamp CMT LEDs deliver the best performance and metal COB reliability in industry-compatible footprints and LES sizes, enabling lighting manufacturers to upgrade their designs for applications such as ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 115 deg
Data Sheet
Cree XLamp CMT2850 LED
Cree
The XLamp® High Current LED Array family is optimized for best-in-class lumen output, efficacy and reliability at high drive currents. XLamp CMT LEDs deliver the best performance and metal COB reliability in industry-compatible footprints and LES sizes, enabling lighting manufacturers to upgrade their designs for applications such as ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 115 deg
Data Sheet
Cree XLamp CMT2870 LED
Cree
The XLamp® High Current LED Array family is optimized for best-in-class lumen output, efficacy and reliability at high drive currents. XLamp CMT LEDs deliver the best performance and metal COB reliability in industry-compatible footprints and LES sizes, enabling lighting manufacturers to upgrade their designs for applications such as ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 115 deg
Data Sheet
Cree XLamp CMT2890 LED
Cree
The XLamp® High Current LED Array family is optimized for best-in-class lumen output, efficacy and reliability at high drive currents. XLamp CMT LEDs deliver the best performance and metal COB reliability in industry-compatible footprints and LES sizes, enabling lighting manufacturers to upgrade their designs for applications such as ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 115 deg
Data Sheet
Cree XLamp MHB-B LED
Cree
The XLamp® MHB-B LED is a new high-power LED that offers a more effective way to lower system costs for high lumen lighting applications, such as high-bay, roadway and outdoor area, than mid-power LEDs. Leveraging key elements of Cree\'s SC5 Technology™ Platform, the ceramic MHB-B LEDs combine high light output, high efficacy and ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 115 deg
Data Sheet
Cree XLamp MHD-G LED
Cree
The XLamp® MHD-G LED is a new category of high-power LED arrays that delivers a better way to achieve low-cost systems than multiple mid-power (MP) LEDs. Built using Cree\'’s high-reliability ceramic-package technology, the XLamp® MHD-G is able to operate at higher temperatures than MP LEDs with no reduction in rated lifetime, ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 115 deg
Data Sheet
Cree XLamp XQ-A LED
Cree
The XLamp® XQ-A LED brings a mid-power, cost-effective option to the proven, compact ceramic XQ package, enabling lighting manufacturers to quickly and easily expand their product portfolio by leveraging a common XQ design. Unlike plastic mid-power LEDs, the ceramic-based XQ-A LEDs are designed to deliver the long-term calculated ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 150 deg
Data Sheet
Cree XLamp XQ-E High Intensity LED
Cree
Available in white and color, the XQ-E High Intensity LEDs are the industry’s smallest high intensity LEDs optimized to deliver maximum candelas through secondary optics, enabling lighting manufacturers to radically reduce system size and power of high intensity color applications. Built on Cree’s breakthrough SC5 Technology™ ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 150 deg
Data Sheet
Cree XLamp XQ-E High Density LED
Cree
The XLamp® XQ-E LED family enables lighting manufacturers to significantly reduce the size and total cost of their LED luminaires without sacrificing light output, efficacy or reliability. The new, game-changing LED packs the lighting-class performance of the XP-E2 into a package that is 78 percent smaller. Available in both white ...
  • LED Color: White
  • Wavelength Range: 380 - 780 nm
  • Output Power (CW): -- W
  • Emission Angle (Divergence): 150 deg
Data Sheet
