Optran® UVWFS Broadband Fiber
Description
ArmadilloSia® is glad to offer a new extremely low loss fiber for the 200 nm to 2000 nm wavelength range. UVWFS broadband fiber owns properties of UV and WF fibers and can be used for a variety of applications, inducing broad spectroscopy and Astronomy Instruments.
Optran® UVWFS Broadband Fiber
Specifications |
|
|---|---|
| Mode Field Diameter (MFD): | N/A um |
| Wavelength Range: | 200-2000nm |
| Cable Length: | N/A m |
| Fiber Core Material: | Silica |
Features
- Low losses @ range 200 nm - 2000 nm
- Any value of NA from 0,12 to 0,28 available upon request
- Very low NA expansion
- Biocompatible material
- Manufactured ISO 9001 compliant facility
Applications
Armadillo® UVWFS optical fiber is the first choice for many applications where different types of fibers are needed simultaneously: spectroscopy, analytical instruments, sensing applications, astronomy, aerospace and avionics, military applications and many more.
For pricing, technical or any other questions please contact the supplier
- No registration required
- No markups, no fees
- Direct contact with supplier
Contact Supplier
How to order?
-
Ships from:
Latvia
-
Sold by:
-
On FindLight:
External Vendor
Claim Armadillo Sia Page to edit and add data
Frequently Asked Questions
The applications of Armadillo® UVWFS optical fiber are spectroscopy, analytical instruments, sensing applications, astronomy, aerospace and avionics, military applications, and many more.
The features of UVWFS broadband fiber are low losses @ range 200 nm - 2000 nm, any value of NA from 0,12 to 0,28 available upon request, very low NA expansion, and biocompatible material.
Optran® UVWFS Broadband Fiber is a new extremely low loss fiber for the 200 nm to 2000 nm wavelength range.
The minimum bending radius of Armadillo® UVWFS optical fiber is 50 × cladding diameter (short-term mechanical stress) and 300 × core diameter (during use with high laser power).
The operating temperature of Armadillo® UVWFS optical fiber is -190 to +350 °C.
