Forensics Light Detection and Analysis Systems

Did You Know?

Did you know that hyperspectral imaging in forensic work can distinguish visually identical bloodstains of different ages by tracking subtle changes in hemoglobin absorption bands around 542 nm and 577 nm? Unlike conventional photography, a forensic hyperspectral camera records dozens to hundreds of contiguous spectral bands, enabling classification of trace materials (fibers, gunshot residue, explosive residues) based on their unique reflectance spectra without consuming the sample. This same principle allows detection of wiped or overprinted writing on questioned documents by isolating ink formulations that differ only slightly in their spectral signatures.
Read more in our Blog

Related Resources

Frequently Asked Questions

This category typically includes spectroscopic and imaging systems used for crime scene and laboratory forensics, such as Raman spectrometers, FTIR microscopes, hyperspectral imagers, UV-Vis-NIR spectrometers, and fluorescence systems. They are applied to trace evidence analysis, document examination, narcotics and explosive identification, gunshot residue characterization, and latent biological stain detection.

Forensics Light Detection Solutions

The Forensics section on FindLight focuses on light detection instruments used in spectral and material analysis for forensic laboratories and field units. These forensics tools rely on UV, visible, and IR illumination and detection to reveal, document, and quantify trace evidence that is not apparent under ambient lighting.

Typical Instruments and Capabilities

Available forensics products include multispectral and hyperspectral imaging systems, portable and benchtop spectrometers, forensic light sources, and camera-based detection kits. These systems are configured for crime scene work, questioned document analysis, gunshot residue inspection, latent biological traces, and material authentication.

Typical specifications for forensics light detection systems may include:

  • Spectral range: UV (200–400 nm), visible (400–700 nm), NIR/SWIR (700–2500 nm) depending on the application.
  • Spectral resolution: from ~1 nm for detailed material analysis to coarser bands for rapid forensics screening.
  • Illumination output: narrowband or broadband sources, often with interchangeable filters and power levels from a few watts to tens of watts.
  • Detector type: CCD/CMOS sensors for imaging, InGaAs arrays for NIR/SWIR, and photodiode or PMT-based modules for highly sensitive forensics measurements.
  • Form factor: handheld or battery-powered devices for field forensics, and rigid benchtop systems for laboratory workflows.

Use Cases in Forensics Workflows

Typical use cases include locating latent fingerprints with fluorescent dyes, detecting bodily fluids via excitation-emission contrast, examining altered or forged documents, analyzing paint and fiber spectra, and differentiating gunshot residue from environmental contaminants. By leveraging tailored spectral bands and high signal-to-noise detection, these forensics tools support both qualitative visualization and quantitative material analysis.

Buyer Guidance on FindLight

When selecting forensics instruments, compare spectral coverage, resolution, sensitivity, working distance, field of view, and portability. Evaluate compatibility with existing cameras, filters, sample holders, and forensic laboratory protocols. On FindLight you can review detailed datasheets, assess technical parameters across multiple forensics vendors, and request quotes directly from manufacturers or distributors. No registration is required to send inquiries, streamlining procurement for forensics labs, crime scene units, and research groups working on advanced material and trace evidence analysis.
