Advanced Forensic Light Source System Laser OR-QG1800

Name: Advanced Forensic Light Source System Laser OR-QG1800
Brand: Hangzhou Hengli Electronic Tech. Co. LTD
Availability: InStock

Description

The Advanced Forensic Light Source System OR-QG1800 is an indispensable tool designed to meet the rigorous demands of modern forensic investigations. This cutting-edge equipment is engineered for versatility, allowing it to be used both in the field and in the laboratory environment. It integrates laser, UV, visible, and infrared light sources, providing a comprehensive suite of illumination options to reveal and enhance a wide variety of evidence.

Fluorescence and enhanced contrast techniques are utilized by the OR-QG1800 to uncover hidden details in evidence that are not visible under normal lighting conditions. This system can illuminate fingerprints, biological fluids, fibers, gunshot residues, and other trace materials with exceptional clarity. The multi-wavelength laser light sources can be used to excite fluorescence in materials, making them glow in distinct colors that can be easily captured and analyzed.

The OR-QG1800 features a robust design with an all-in-one construction that is both moisture-proof and shockproof, ensuring durability in challenging environments. It offers a maximum output power of 12W and continuous, adjustable light output to suit various investigative needs. The system includes an external lithium iron phosphate battery pack for field operations, providing extended operational time and flexibility.

Equipped with 19 wavebands, the OR-QG1800 delivers uniform light output with spot evenness of at least 85%, ensuring consistent and reliable results. Its powerful illumination capabilities, coupled with advanced features like adjustable power settings, a variety of laser light beam sizes, and an extensive range of wavelengths, make it an essential asset for forensic professionals.

Whether for detecting biological evidence such as blood, semen, and saliva, or for enhancing the visibility of latent fingerprints and other trace materials, the OR-QG1800 stands out as the premier choice for forensic light source equipment.

Specifications

Max. Output Power:	≥ 12 W
Max. Power Of Main Engine:	≥ 360W, Continuous and adjustable output light
Power Supply:	220VAC or 24VDC battery pack
Battery:	External lithium iron phosphate battery pack; Capacity: 12Ah; Charging voltage: 29.2V
Laser Output Mode:	400μm multimode fiber, Fiber length: ≥ 2.5m
Laser Light Beam Size:	DIA.: ≥ 11cm at 0.5m, DIA.: ≥ 25cm at 1m
LED Visible Light Beam Size:	DIA.: ≥ 29cm at 0.5m, DIA.: ≥ 60cm at 1m
Light Beam Features:	Uniform light output with spot evenness ≥ 85%
Structural Feature:	All-in-one machine, moisture proof and shockproof
Wave Bands Output:	Single machine outputs 19 wave bands

Download Data Sheet

Features

Designed for versatile use in both field and laboratory settings

Capable of revealing evidence through fluorescence or enhanced contrast

Supports a wide range of wavelengths, including laser, visible, UV, and IR light sources

Uniform light output with high spot evenness (≥ 85%)

Moisture-proof and shockproof all-in-one machine design

Continuous and adjustable light output with max power of main engine ≥ 360W

External lithium iron phosphate battery pack for portability

Applications

Detection of fingerprints on various surfaces

Identification of biological evidence such as blood, semen, saliva, urine, and vaginal fluids

Enhanced visualization of bruising, hair, fibers, and footprints

Examination of ninhydrin and super glue treated fingerprints

General crime scene searching and evidence collection

Name

Work Email

Organization (recommended)

Your message to supplier

Get quotes from similar suppliers

Add to Watchlist (My Watchlist)

Ships from:

China

Sold by:

Hangzhou Hengli Electronic Tech. Co. LTD

On FindLight:

since 2017

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What types of evidence can the OR-QG1800 detect?

The OR-QG1800 can detect a wide range of evidence, including biological fluids (blood, semen, saliva, urine, vaginal fluids, sweat), fingerprints, fibers, bruising, hair, footprints, stamps, Ninhydrin-treated fingerprints, Super glue-treated fingerprints, and general traces of material evidence.

What is the maximum output power of the OR-QG1800?

The OR-QG1800 has a maximum output power of 12W, with the main engine capable of delivering continuous and adjustable light output up to 360W.

How is the OR-QG1800 powered?

The OR-QG1800 can be powered by a 220VAC power supply or a 24VDC battery pack. It includes an external lithium iron phosphate battery pack with a capacity of 12Ah and a charging voltage of 29.2V.

What are the features of the OR-QG1800's light beam?

The OR-QG1800 offers uniform light output with a spot evenness of at least 85%. The laser light beam size is ≥ 11cm at 0.5m and ≥ 25cm at 1m, while the LED visible light beam size is ≥ 29cm at 0.5m and ≥ 60cm at 1m.

Is the OR-QG1800 portable for field use?

Yes, the OR-QG1800 is designed for portability and versatility. It features an all-in-one, moisture-proof, and shockproof design, making it suitable for use in both field and lab environments. The external battery pack allows for extended operation time in the field.

Can the OR-QG1800 be used to detect fluorescence in materials?

Yes, the OR-QG1800 can be used to excite fluorescence in materials. When illuminated with laser light of one color, materials can re-emit light in a different color, making it easier to detect and analyze evidence.
