Description
Walthy Precision Co., Ltd. presents custom optical slits engineered for precision and versatility. These slits, meticulously crafted from high-quality materials like glass, quartz, or 304 stainless steel, offer exceptional performance for optical systems and educational experiments.
With customizable dimensions, slit widths ranging from 5 to 1000 μm, and precision pinholes sized from 1 to 1000 microns, these slits are ideal for image analysis and a wide range of optical applications.
Optical Slits
Specifications
| Slit Width: | 5 um |
|---|---|
| Slit Length: | 25.4 mm |
| Mounting: | Mounted, Unmounted |
| Part Diameter: | 9.5 mm |
| Small Quantity: | Acceptable |
| Material: | 304 Stainless Steel Or customized |
| Thickness: | 0.05mm or customized |
| Dimension Tolerance: | +/-10% |
| Custom Made: | Available |
| Slit Width: | 5-1000um |
| Finish: | Can be blacked |
| Pinhole: | Available |
Download Data Sheet
Features
- Custom Made: Tailored to meet specific requirements
- Versatile Thickness: 1.5 mm or customized for optimal performance
- Adjustable Outer Diameter: 25.4 mm or customized to suit diverse needs
- Flexible Slit Length: Options for 25.4 mm or customized lengths
- Precision Pinholes: Available in various sizes from 1 to 1000 microns
- Type: Unmounted slits for easy integration
- Material Options: Choose from glass, quartz, or customized materials
- Small Quantity Accepted: Suitable for projects of varying scales
- Reasonable Price: Competitive pricing without compromising quality
- Finish Options: Can be blacked for enhanced performance
- Downloadable Data Sheet: Detailed specifications for reference
Applications
- Ideal for optical systems and educational optical experiments
- Suitable for image analysis in research and educational settings
- Widely used in laboratories, universities, and research institutions
- Versatile applications in spectroscopy, microscopy, and imaging technology
Frequently Asked Questions
What materials are available for the optical slits?
The materials available for the optical slits include glass, quartz, copper, gold, alumina ceramic, tungsten, and molybdenum.
Can the slit width be customized?
Yes, the slit width can be customized according to the customer's request, with options ranging from 5um to 1000um.
What applications are the optical slits suitable for?
The optical slits are suitable for optical systems, educational optical experiments, spectrophotometer image analysis, and spatial filtering.
Are small quantity orders accepted?
Yes, small quantity orders are acceptable for the custom-made optical slits.
Are pinholes and apertures available for the optical slits?
Yes, pinholes and apertures ranging from 5um to 1000um are available for the optical slits.
