Description

Introducing the Precision Air Slit, a meticulously engineered component designed to meet the highest standards of optical performance. With a width of 100 µm, this air slit is crafted to provide exceptional precision and reliability in various optical applications. Its slender design ensures minimal interference, making it an ideal choice for projects requiring exacting specifications.

The Precision Air Slit boasts a length of 12 mm, offering ample coverage while maintaining its compact form. This balance of size and functionality ensures that the slit can be seamlessly integrated into a wide range of optical systems. Its dimensions are carefully calibrated to deliver optimal performance without compromising on quality or durability.

Constructed from high-grade aluminium, the substrate of this air slit measures 25.4 mm in diameter and 0.2 mm in thickness. This choice of material not only provides robust structural integrity but also enhances the slit’s ability to withstand various environmental conditions. The aluminium substrate ensures longevity and consistent performance, making it a reliable component for precision optical tasks.

Manufactured by DIY-Optics GmbH, a leader in optical components, the Precision Air Slit reflects the company’s commitment to quality and innovation. Located in Sarnen, Switzerland, DIY-Optics GmbH is renowned for its expertise in delivering high-performance optical solutions tailored to meet the needs of professionals around the globe.

Precision Air Slit - 100um / 12mm

DIY-Optics GmbH

Specifications

Slit Width: 100 um
Slit Length: 12 mm
Mounting: Unmounted
Part Diameter: 25.4 mm
Thickness: 0.2 mm

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • Precision Air Slit: Designed for high-precision applications requiring exact measurements and control.
  • Width: 100 µm - Ensures precise and accurate slitting for detailed work.
  • Length: 12 mm - Suitable for a variety of optical setups and configurations.
  • Substrate Diameter: 25.4 mm - Standard size for compatibility with most optical systems.
  • Substrate Thickness: 0.2 mm - Thin and lightweight, allowing for easy integration into existing systems.
  • Substrate Material: Aluminium - Provides durability and resistance to environmental factors.

Applications

  • High-Precision Optical Experiments: Ideal for use in laboratory settings where precise light control is required.
  • Spectroscopy: Suitable for applications in spectroscopy where accurate light dispersion is necessary.
  • Laser Beam Shaping: Can be used to shape and control laser beams in various optical setups.
  • Microscopy: Enhances imaging quality by providing precise light slits for microscopes.
  • Photolithography: Useful in photolithography processes for creating fine patterns on substrates.
  • Optical Calibration: Assists in the calibration of optical instruments by providing a known slit size.
  • Research and Development: Essential for R&D projects that require precise optical components.
  • Educational Demonstrations: Perfect for educational settings to demonstrate principles of optics and light behavior.

Frequently Asked Questions

What is the width of the Precision Air Slit?
The width of the Precision Air Slit is 100 µm.
What is the length of the Precision Air Slit?
The length of the Precision Air Slit is 12 mm.
What is the diameter of the substrate for the Precision Air Slit?
The substrate diameter for the Precision Air Slit is 25.4 mm.
What is the thickness of the substrate for the Precision Air Slit?
The substrate thickness for the Precision Air Slit is 0.2 mm.
What material is the substrate of the Precision Air Slit made from?
The substrate of the Precision Air Slit is made from aluminium.
Where is DIY-Optics GmbH located?
DIY-Optics GmbH is located at Kernserstrasse 17, 6060 Sarnen, Switzerland.
What type of product is this datasheet describing?
This datasheet is describing a Precision Air Slit.

Got more questions? Use the inquiry form to ask the supplier directly.
