Description
Laser Line Mirrors on N-BK7 Substrate are highly reflective mirrors designed for non-critical laser applications in the 350-1570 nm wavelength range. These mirrors offer >99.5% reflectivity and are made from BK7 optical substrate, providing a low-cost alternative to UV grade fused silica mirrors.
They are optimized for specific laser wavelengths and can be used at either a 45° or 0° angle of incidence. The mirrors are coated with a multilayer dielectric or IBS coating, ensuring high polishing quality for low wavefront distortion, low scattering, and a high damage threshold.
Laser Line Mirrors on N-BK7 Substrate 035-0530
Specifications
Substrate Material: | BK7, Fused Silica, UV Fused Silica |
---|---|
Wavelength Range: | 527 – 532 nm |
Angle Of Incidence (AOI): | 45 deg |
Flatness (Coated Surface): | lambda/10 |
Surface Quality: | 20-10 scratch-dig |
Reflectivity (Rs, Rp): | 99.5 % |
Diameter: | 50.8 mm |
Thickness: | 8 mm |
Central Diameter: | 12.7 mm |
Diameter Tolerance: | + 0.00 mm, - 0.12 mm |
Thickness Tolerance: | ±0.25 mm |
Clear Aperture: | Exceeds central 85% of diameter |
Features
- Highly reflective mirrors with >99.5% reflectivity
- Designed to work at 45° or 0° angle of incidence
- Made from BK7 optical substrate
- Low-cost alternative for non-critical laser applications
- Coated with multilayer dielectric or IBS coating
- Suitable for UV, VIS, and NIR spectra
- High damage threshold and low wavefront distortion
Applications
- Laser systems and devices
- Laser beam steering and alignment
- Scientific research and spectroscopy
- Industrial and manufacturing laser processes
- Non-critical laser applications in the UV, VIS, and NIR range
Frequently Asked Questions
What are Nd:YAG Laser Line Mirrors?
Nd:YAG Laser Line Mirrors are dielectric reflectors designed for 45° or 0° angle of incidence, suitable for fundamental Nd:YAG laser 1064 nm, frequency-doubled 532 nm, frequency-tripled 355 nm and frequency quadrupled 266 nm wavelength application.
What is the price range of Nd:YAG Laser Line Mirrors?
The price range of Nd:YAG Laser Line Mirrors varies depending on the size and wavelength. Please refer to the catalogue number and price in the datasheet for more information.
What are the features of Nd:YAG Laser Line Mirrors?
Nd:YAG Laser Line Mirrors feature high polishing quality, low scattering, and high damage threshold, enabling perfect beam steering for Nd:YAG lasers.
What is the damage threshold of BK7 laser line mirrors?
The damage threshold of BK7 laser line mirrors is 5 J/cm2, 8 nsec pulse, 1064 nm typical.
What is the substrate material used in Nd:YAG Laser Line Mirrors?
Two kinds of substrate material are available: UV grade Fused Silica or BK7 glass.
