Nonlinear crystals--KTA

Name: Nonlinear crystals--KTA
Brand: DIEN TECH
Availability: InStock

Description

Potassium Titanyle Arsenate (KTiOAsO4), or KTA crystal, is an excellent nonlinear optical crystal for Optical Parametric Oscillation (OPO) application. It has better non-linear optical and electro-optical coefficients, significantly reduced absorption in the 2.0-5.0 µm region, broad angular and temperature bandwidth, low dielectric constants. And its low ionic conductivities result in higher damage threshold compared with KTP .

Specifications

Crystal Type:	KTA (KTiOAsO4)
Phase Mathcing Type:	Not Applicable
Mounting:	Unmounted
Width:	5 mm
Height:	5 mm
Length:	5 mm
Flatness:	Not Available
Surface Quality (Scratch-Dig):	20-10
AR Coating:	Both Sides

Download Data Sheet

Features

Optical and Nonlinear Optical Properties:

• Transparency Range: 350-5300nm

• Absorption Coefficients: @ 1064 nm<0.05%/cm

@ 1533 nm<0.05%/cm

@ 3475 nm<5%/cm

• NLO Susceptibilities (pm/V): d31 = 2.76, d32 = 4.74, d33 = 18.5 , d15 = 2.3, d24 = 3.2

• Electro-optical constants (pm/V) (low frequency): ｒ33=37.5; ｒ23=15.4; ｒ13=11.5

• SHG Phase Matchable Range: 1083-3789nm

Name

Work Email

Organization (recommended)

Your message to supplier

Get quotes from similar suppliers

Add to Watchlist (My Watchlist)

Ships from:

China

Sold by:

DIEN TECH

On FindLight:

since 2018

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What is KTA crystal used for?

KTA crystal is an excellent nonlinear optical crystal for Optical Parametric Oscillation (OPO) application.

What are the optical and nonlinear optical properties of KTA crystal?

The transparency range of KTA crystal is 350-5300nm. The absorption coefficients at 1064 nm, 1533 nm, and 3475 nm are less than 0.05%/cm, less than 0.05%/cm, and less than 5%/cm, respectively. The NLO susceptibilities (pm/V) are d31 = 2.76, d32 = 4.74, d33 = 18.5, d15 = 2.3, and d24 = 3.2. The electro-optical constants (pm/V) (low frequency) are r33=37.5, r23=15.4, and r13=11.5. The SHG Phase Matchable Range is 1083-3789nm.

What are the features of KTA crystal?

KTA crystal has better non-linear optical and electro-optical coefficients, significantly reduced absorption in the 2.0-5.0 µm region, broad angular and temperature bandwidth, low dielectric constants, and its low ionic conductivities result in higher damage threshold compared with KTP.

What is the crystal structure of KTA crystal?

The crystal structure of KTA crystal is orthorhombic, with a point group of mm2. The lattice parameters are a=13.125Å, b=6.5716Å, and c=10.786Å.

What is the melting point of KTA crystal?

The melting point of KTA crystal is 1130˚C.
