Nonlinear crystal - BiB3O6 (BIBO) - Get a price quote from DIEN TECH

Name: Nonlinear crystal - BiB3O6 (BIBO)
Brand: DIEN TECH
Availability: InStock

Description

BiB3O6 (BIBO) is a newly developed nonlinear optical crystal. It possesses large effective nonlinear coefficient, high damage threshold and inertness with respect to moisture. Its nonlinear coefficient is 3.5 - 4 times higher than that of LBO, 1.5 -2 times higher than that of BBO. It is a promising doubling crystal to produce blue laser.

Specifications

Crystal Type:	BIBO (BiB3O6)
Phase Mathcing Type:	Not Applicable
Mounting:	Mounted
Width:	10 mm
Height:	10 mm
Length:	15 mm
Flatness:	<= Lambda/8
Surface Quality (Scratch-Dig):	10-5
AR Coating:	Both Sides

Download Data Sheet

Name

Work Email

Organization (recommended)

Your message to supplier

Get quotes from similar suppliers

Add to Watchlist (My Watchlist)

Ships from:

China

Sold by:

DIEN TECH

On FindLight:

since 2018

Got Questions? Ask Above ▲

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply

Frequently Asked Questions

What is BiB3O6 (BIBO)?

BiB3O6 (BIBO) is a newly developed nonlinear optical crystal that possesses large effective nonlinear coefficient, high damage threshold and inertness with respect to moisture.

What is the nonlinear coefficient of BiB3O6 (BIBO)?

The nonlinear coefficient of BiB3O6 (BIBO) is 3.5-4 times higher than that of LBO and 1.5-2 times higher than that of BBO.

What is the transparency range of BiB3O6 (BIBO)?

The transparency range of BiB3O6 (BIBO) is 286-2500nm.

What is the damage threshold of BiB3O6 (BIBO)?

The damage threshold of BiB3O6 (BIBO) is greater than 0.3 GW/cm2 for 1064nm, TEM00, 10ns, 10HZ.

What is the promising application of BiB3O6 (BIBO)?

BiB3O6 (BIBO) is a promising doubling crystal to produce blue laser.
