Page 3 - Laser Crystals

Nd: YAG Crystal
Bluebean Optical Tech Ltd
Add to watch list
Nd: YAG Crystal
Compare
Nd:YAG(Neodymium-doped Yttrium Aluminium Garnet) laser crystal provides the laser system designer with the most versatile solid state laser source in use today. With thousands of systems in daily use, Nd:YAG continues as the best of the rare earth garnet laser materials characterised by four level laser operation, permitting low ...

Specifications
Type Of Crystal: Nd:YAG
Crystal Diameter: -- mm
Crystal Length: -- mm
AR Coating: Uncoated
Data Sheet
CRYSTECH Nd:YAG Crystal
CRYSTECH Inc.
Add to watch list
CRYSTECH Nd:YAG Crystal
Compare
Neodymium-doped Yttrium-Aluminum Garnet (Nd:YAG) crystal is the best of the rare earth garnet materials that are characterized by four-level system which permits low threshold operation both in pulsed and CW mode. It is the most mature and widely used solid-state laser material adopted by R&D, medical, industrial and military ...

Specifications
Type Of Crystal: Nd:YAG
Crystal Diameter: 3-20 mm
Crystal Length: 1-180 mm
AR Coating: One side, Both sides, Uncoated
Http://www.crystech.com/ : .
Data Sheet
Nd:YAG Crystal Rod
ANHUI CRYSTRO CRYSTAL MATERIALS Co., Ltd.
Add to watch list
Nd:YAG Crystal Rod
Compare
Nd:YAG is a common laser crystal.Because of its many basic performance,Nd:YAG is still often used in near-far-infrared solid-state lasers.

Specifications
Type Of Crystal: Nd:YAG
Crystal Diameter: 2,5,6,8,10,12 mm
Crystal Length: up to 190 mm
AR Coating: Both sides
Dimension: D3 - D40 mm
...
Data Sheet
Tb3Ga5O12 TGG Crystals
ANHUI CRYSTRO CRYSTAL MATERIALS Co., Ltd.
Add to watch list
Tb3Ga5O12 TGG Crystals
Compare
TGG is an excellent magneto-optical crystal used in various Faraday devices（Rootator and Isolator）in the range of 400nm-1100nm,excluding 475-500nm.

Specifications
Type Of Crystal: TGG
Crystal Diameter: 1,2,2.5,3,5-102 mm
Crystal Length: up to 150 mm
AR Coating: Both sides
Verdet (rad/M/T): 190/134/40@532nm/633nm/1064nm
...
Data Sheet
GGG SGGG Crystal Substrates
ANHUI CRYSTRO CRYSTAL MATERIALS Co., Ltd.
Add to watch list
GGG SGGG Crystal Substrates
Compare
Gadolinium gallium garnet(GGG) is a special substrate magneto optical flims. In optical commuication equipment, a large number of 1.3 and 1.5 micron optical isolators are needed, and the core component is YIG or BIG film placed in the magnetic field. Different tangential GGG single crystal substrates can be matched with the lattice ...

Specifications
Type Of Crystal: GGG
Crystal Diameter: up to 104 mm
Crystal Length: up to 150 mm
AR Coating: Uncoated
Material: GGG/SGGG
...
Data Sheet
TSAG Crystal
ANHUI CRYSTRO CRYSTAL MATERIALS Co., Ltd.
Add to watch list
TSAG Crystal
Compare
Property ValueChemical Formula  Tb3Sc2Al3O12Lattice Parameter  a=12.3ÅDensity 5.91g/cm3Melting Point 1970℃±10℃Growth Method CzochralskiCrystal Structure  Cubic, Space group Ia3dDensity 5.91 g/cm3

Specifications
Type Of Crystal: TSAG
Crystal Diameter: 50 mm
Crystal Length: 120 mm
AR Coating: Both sides
Verdet (rad/M/T): 218/152/65@532nm/633nm/1064nm
...
Data Sheet
Ho:Tm:YLF Crystals
HG Optronics, Inc.
Add to watch list
Ho:Tm:YLF Crystals
Compare
Ho:Tm:YLF crystal is 2μm laser crystal with Tm ion sensitized. Conveniently pumped at 792nm, 2.05μm linearly polarized beam is output. Working mode is: First, Tm ion absorbs 792nm pump light energy, and transfers the energy to upper laser level of Ho ion by non-radiative transition, then Ho ion emits laser. The advantage of above ...

Specifications
Type Of Crystal: YLF
Crystal Diameter: 3~9.5 mm
Crystal Length: 5~120 mm
AR Coating:
Dopant Concentration: Tm: 0~10at% Ho: 0~3at% Upon request of customer
...
Data Sheet
Ho:YLF Crystals
HG Optronics, Inc.
Add to watch list
Ho:YLF Crystals
Compare
Ho:YLF is the important middle infrared laser crystal. Ho:YLF pumped ZGP crystal at 1.9μm, so 2.05μm linearly polarized beam can be output.

Specifications
Type Of Crystal: YLF
Crystal Diameter: 3~9.5 mm
Crystal Length: 5~120 mm
AR Coating: Both sides
Dopant Concentration: Ho: 0~3at% Upon request of customer
...
Data Sheet
Tm:YLF Crystals
HG Optronics, Inc.
Add to watch list
Tm:YLF Crystals
Compare
Tm:YLF is the important middle infrared laser crystal. Because Tm:YLF is negative uniaxial crystal, whose thermal refractive index coefficient is negative, some thermal distortion may be counteracted and high-quality light can be output. Conveniently pumped at 792nm, 1.9μm linearly polarized beam is ...

Specifications
Type Of Crystal: Other
Crystal Diameter: 3~9.5 mm
Crystal Length: 5~120 mm
AR Coating: Both sides
Orientation: <100> or <001> within 5°
...
Data Sheet
CTH:YAG CRYSTAL
EOT
Add to watch list
CTH:YAG CRYSTAL
Compare
Electro Optics Technology GmbH has been growing CTH:YAG for over 20 years. During this time, material properties and qualities have improved to make it one of the best solutions on the market for 2.1 µm lasers. Our high quality CTH:YAG is an excellent choice for medical laser applications. With over 20 years of polishing ...

Specifications
Type Of Crystal: Other
Crystal Diameter: 4-6 mm
Crystal Length: 100-130 mm
AR Coating: Both sides
Data Sheet
ND:KGW CRYSTALS NdKGW-0324-02
EKSMA OPTICS
Add to watch list
ND:KGW CRYSTALS NdKGW-0324-02
Compare
Nd:KGW crystals are low lasing threshold highly efficient laser material exceptionally suitable for laser rangefinding applications. The efficiency of Nd:KGW lasers is 3–5 times higher than that of Nd:YAG lasers. Nd:KGW laser medium is one of the best choices ensuring effective laser generation at low pump energies (0.5–1 J). These ...

Specifications
Type Of Crystal: Nd:KGW
Crystal Diameter: 3 mm
Crystal Length: 50 mm
AR Coating: Both sides
Data Sheet
YB:KGW AND YB:KYW CRYSTALS YbKYW-0618-01
EKSMA OPTICS
Add to watch list
YB:KGW AND YB:KYW CRYSTALS YbKYW-0618-01
Compare
Yb-Doped Potassium Gadolinium Tungstate (Yb:KGd(WO4)2) and Yb-doped Potassium Itrium Tungstate (Yb:KY(WO4)2) single crystals are the laser crystals for diode or laser pumped solid-state laser applications.

Specifications
Type Of Crystal: Yb:KGW, Yb:KYW
Crystal Diameter: -- mm
Crystal Length: 5 mm
AR Coating: Both sides
Data Sheet
ND:YAG CRYSTALS E-Y-3-0.9-A/A
EKSMA OPTICS
Add to watch list
ND:YAG CRYSTALS E-Y-3-0.9-A/A
Compare
Neodymium Doped Yttrium Aluminum Garnet - Nd:YAG laser crystal is the most popular lasing media for solid-state lasers. Good fluorescence lifetime, thermal conductivity and robust nature make Nd:YAG laser crystal suitable for high power continuous wave, high intensity q-switched and single mode operation. EKSMA OPTICS offers high ...

Specifications
Type Of Crystal: Nd:YAG
Crystal Diameter: 3 mm
Crystal Length: 53 mm
AR Coating: One side, Both sides
Data Sheet
ND:YLF Crystal by HG Optronics
HG Optronics, Inc.
Add to watch list
ND:YLF Crystal by HG Optronics
Compare
Nd:YLF is an excellent crystal for modelocked operation because it combines the characteristics of weak thermal lensing, large fluorescence line width and naturally polarized oscillation.

Specifications
Type Of Crystal: Nd:YLF
Crystal Diameter: 3~10 mm
Crystal Length: 5-120 mm
AR Coating: One side, Both sides, Uncoated
Dopant Concentration: ND:( 0.1 ~ 1.2) atm%±0.1%
...
Data Sheet
nortus Optronic Laser Crystals
DOEHRER Elektrooptik GmbH
Add to watch list
nortus Optronic Laser Crystals
Compare
Thanks to longstanding partnerships with crystal manufacturers in China and the USA, we are able to supply a wide range of different crystal types.

Specifications
Type Of Crystal: Nd:YAG, Nd:YVO4, Yb:KGW, Nd:KGW, Nd:YLF, Nd:GdVO4, Other
Crystal Diameter: 1 mm
Crystal Length: 1 mm
AR Coating: One side, Both sides
Data Sheet
Robust Laser Materials
Davis Marketing International LLC
Add to watch list
Robust Laser Materials
Compare
Davis Marketing International features YAG from Laser Materials Corporation, and VANADATE materials from the highest quality growers in the Pacific Rim. Among the customers/industries using our materials are universities doing applied research, medical device manufacturers, Industrial manufacturers and defense contractors building ...

Specifications
Type Of Crystal: Nd:YAG, Ti:Sapphire, Yb:YAG
Crystal Diameter: -- mm
Crystal Length: -- mm
AR Coating: One side, Both sides
Data Sheet
Neodymium Doped Yttrium Aluminum Aluminum Garnet Nd:YAG Crystal
Hobbite Co Ltd
Add to watch list
Neodymium Doped Yttrium Aluminum Aluminum Garnet Nd:YAG Crystal
Compare
Neodymium Doped Yttrium Aluminum Garnet-Nd:Y3A15O12(Nd:YAG) with high efficiency, high beam damage threshold and good heat conductivity, has been applied to activate and sensitize ion so as to enhance the laser output. Therefore, it has been continuous to be the most widely used solid state laser material. At room temperature, ...

Specifications
Type Of Crystal: Nd:YAG
Crystal Diameter: -- mm
Crystal Length: -- mm
AR Coating: Uncoated
Data Sheet
YTTRIUM VANADATE YVO4 CRYSTALS
Hobbite Co Ltd
Add to watch list
YTTRIUM VANADATE YVO4 CRYSTALS
Compare
Yttrium Vanadate (YVO4) crystals have good mechanical and physical properties and are ideal for optical polarizing components because of their wide transparency range and large birefringence. They are an excellent synthetic substitute for Calcite (CaCO3) and rutile (TiO2) in many applications including fiber optic isolators and ...

Specifications
Type Of Crystal: YVO4
Crystal Diameter: 1-25 mm
Crystal Length: 1-25 mm
AR Coating: One side, Both sides, Uncoated
Data Sheet
Yb:YAG Crystal by HG Optronics
HG Optronics, Inc.
Add to watch list
Yb:YAG Crystal by HG Optronics
Compare
It is more suitable for diode-pumping than the traditional Nd-doped systems. It can be pumped at 0.94 μm laser output. Compared with the commonly used Nd:YAG crystal, Yb:YAG crystal has a much larger absorption bandwidth to reduce thermal management requirements for diode lasers, a longer upper-state lifetime, three to four times ...

Specifications
Type Of Crystal: Yb:YAG
Crystal Diameter: N/A mm
Crystal Length: N/A mm
AR Coating: One side, Both sides, Uncoated
Doping(atm%):: 1.0% ~ 35%
...
Data Sheet
Ti:Sapphire Crystal by HG Optronics
HG Optronics, Inc.
Add to watch list
Ti:Sapphire Crystal by HG Optronics
Compare
Ti:Sapphire crystal is the most widely used tunable solid-state laser material combining the supreme physical and optical properties with the extremely broad lasing range.  Its lasing bandwidth can support pulses < 10fs making it the crystal of choice for femtosecond mode-locked oscillators and amplifiers.  The ...

Specifications
Type Of Crystal: Ti:Sapphire
Crystal Diameter: N/A mm
Crystal Length: N/A mm
AR Coating: One side, Both sides, Uncoated
Orientation:: Optical axis C normal to rod axis
...
Data Sheet
Erbium Laser Glass by HG Optronics
HG Optronics, Inc.
Add to watch list
Erbium Laser Glass by HG Optronics
Compare
Er3+/Yb3+ co-doped phosphate glass — as the 1540nm eye-safe radiation sources pumped by LD which can emit eye-safe 1540nm laser radiation directly used in laser ranging finder and telecommunication communication.

Specifications
Type Of Crystal: Er Glass
Crystal Diameter: N/A mm
Crystal Length: N/A mm
AR Coating: One side, Both sides, Uncoated
Cross Section For Stimulated Emission (10-20cm2): 0.8
...
Data Sheet
Nd:YAG Crystal by HG Optronics
HG Optronics, Inc.
Add to watch list
Nd:YAG Crystal by HG Optronics
Compare
Nd:YAG is the earliest and most famous laser host crystal. Since it combines great advantages in many basic properties, Nd:YAG is the ubiquitous presence for near-infrared solid-state lasers and their frequency-doubler, tripler, and higher order multiplier.

Specifications
Type Of Crystal: Nd:YAG
Crystal Diameter: N/A mm
Crystal Length: N/A mm
AR Coating: One side, Both sides, Uncoated
Doping(atm%):: 0.1% ~ 2.5%
...
Data Sheet
Bonding Crystal by HG Optronics
HG Optronics, Inc.
Add to watch list
Bonding Crystal by HG Optronics
Compare
Bonding (Diffusion bonded) crystals consist of one laser crystal and one or two undoped material. They are combined by optical contact method and further bonded under high temperatures. Diffusion Bonded Crystal helps to decrease the thermal lens effect considerably. We can offer Bonding Crystals as blow:YVO4+ Nd:YVO4 + YVO4GdVO4+ ...

Specifications
Type Of Crystal: Other
Crystal Diameter: 1 mm
Crystal Length: 130 mm
AR Coating: Both sides
Parallelism: 10"
...
Data Sheet
Nd:YVO4 Crystal by HG Optronics
HG Optronics, Inc.
Add to watch list
Nd:YVO4 Crystal by HG Optronics
Compare
Nd:YVO4 is one of the most promising commercially available diode pumped solid state laser materials. It has high laser induced damage threshold and good mechanical in addition to optical properties. Its large stimulated emission cross-section and high absorption of pump laser make it a right crystal for pocket laser. Nd: YVO4 can ...

Specifications
Type Of Crystal: Nd:YVO4
Crystal Diameter: 40 mm
Crystal Length: 60 mm
AR Coating: Both sides
Damage Threshold: 750MW/CM2 at 1064nm, TEM00, 10ns, 10Hz
...
Data Sheet
Large AFB Components
Onyx Optics Inc
Add to watch list
Large AFB Components
Compare
Onyx welcomes all inquiries about the feasibility of AFB® composite optical components. We are interested in discussing and manufacturing new material combinations and structural geometries. It is our goal to provide high-quality composites that will provide a solution for your system\'s needs, so we encourage any design ...

Specifications
Type Of Crystal: Other
Crystal Diameter: 30 mm
Crystal Length: 30 mm
AR Coating: Uncoated
Data Sheet
