Gentec-EO M6-6-IN Integrating Sphere Detector

Name: Gentec-EO M6-6-IN Integrating Sphere Detector
Brand: Gentec-EO

Description

The Gentec-EO M6-6-IN is a precision integrating sphere detector designed for laser energy measurement applications. With the capability to measure laser energies up to 200 µJ, this reliable laser energy meter is an invaluable tool for professionals in laser research, development, and testing.

The M6-6-IN features high-quality components and precise calibration, ensuring accurate energy measurements across a wide spectral range.

Specifications

Max Measurable Energy:	0.2 mJ
Max Repetition Rate:	200000 Hz
Effective Aperture:	6 mm
Spectral Range:	0.9 – 1.6 um
Typical Rise Time:	150 ns
Repeatability:	±1 %
Noise Equivalent Energy:	2 nJ
Maximum Pulse Width:	100 ns
Energy Calibration Uncertainty:	±4 %
Maximum Power:	5.0 W
Absorber:	InGaAs
Dimensions 3:	8.1 Ø x 58.4D mm
Weight:	0.15 kg

Got questions about specs? Use the inquiry form to ask.

Download Data Sheet

Features

Wide Measurement Range: Measures laser energy up to 200 µJ, accommodating a broad range of laser sources
High Precision: Offers exceptional repeatability with ±1% accuracy and a low noise equivalent energy of just 2 nJ
Broad Spectral Range: Covers the spectral range from 0.9 to 1.6 μm, making it suitable for various laser applications
Fast Response: Features a typical rise time of 150 ns, enabling rapid energy measurements
High Repetition Frequency: Supports measurements at a maximum repetition frequency of 200,000 Hz
Energy Calibration: Calibrated with a ±4% uncertainty to ensure accurate readings
Maximum Pulse Width: Capable of measuring pulses as short as 100 ns

Applications

Laser Research: Essential for laser characterization, development, and experimentation
Industrial Laser Processing: Ensures laser systems operate at desired energy levels for cutting, welding, and marking applications
Quality Control: Used in manufacturing to verify laser system performance
Laser Safety: Ensures lasers comply with safety standards by measuring their energy output
Medical Laser Systems: Vital for evaluating laser output in medical and surgical applications

Request Quote

To: Gentec-EO
Re: Gentec-EO M6-6-IN Integrating Sphere Detector

Name

Work Email

Organization

Country

Your message to supplier

FAST RESPONSE

Thank you, your message was sent successfully.

Ships from:: Canada
Sold by:: Gentec-EO ✓ Verified Supplier
On FindLight:: since 2014

Why contact via FindLight?

Message the supplier directly
No signup or account needed
No FindLight fees or markups
Expect a fast reply
Autofill forms with a Buyer Account

Frequently Asked Questions

What is the MACH 6 Joulemeter used for?

The MACH 6 Joulemeter is used to measure every pulse at up to 200 kHz with 12-bit digital accuracy and capture up to 4 million pulses in real time.

What is the maximum energy and average power that can be measured with the MACH 6 laser energy meter?

The maximum energy that can be measured with the MACH 6 Joulemeter ranges from 20 mJ to 200 mJ depending on the head used, and the maximum average power is 25 W.

What are the different heads available for the MACH 6 laser energy detector?

The MACH 6 Joulemeter has several heads to choose from, including Silicon, InGaAs, and Pyroelectric heads for a broad wavelength and energy range.

What is the effective aperture of the MACH 6 laser energy meter?

The effective aperture of the MACH 6 Joulemeter ranges from 6 mm Ø to 12.5 mm Ø depending on the head used.

What are the diagnostic features available in the user-friendly software of the MACH 6 energy meter?

The user-friendly software of the MACH 6 Joulemeter includes Live Mode, Strip Chart, Histogram and Statistics displays, FFT display of pulse energy data for temporal diagnostics, and Life Test Mode to automate laser testing.
