Description
The MGON series high precision goniometer is designed for accurate angular adjustment and positioning. These goniometers provide precise control and stability, making them suitable for fiber alignment and other applications requiring precise angular positioning.
They feature a compact design with different models available, offering various travel angles and center heights. With micrometer actuators and low rotation center runout, these goniometers ensure smooth and accurate rotation. The MGON series is lightweight and versatile, making it an ideal choice for applications that demand high precision goniometric adjustments.
MGON40-40SL-SR High Precision Goniometer
Specifications
| Travel Range: | -7 – 7 deg |
|---|---|
| Center Of Rotation: | 40 mm |
| Load Capacity (horizontal): | 3 kg |
| Load Capacity (vertical): | Not Specified |
| Table Size: | 40 mm |
| Guiding Mechanism: | High-Precision Profiled Rails |
| Axes Of Motion: | One Axis |
| Drive Position: | Center Drive |
| Material: | Stainless Steel |
| Weight: | 0.12 kg |
| Thickness: | 17 mm |
| Actuators: | Micrometer |
| Rotation Center Runout: | ≤15 µm |
Download Data Sheet
Features
- High precision angular adjustment for accurate positioning
- Compact and lightweight design
- Micrometer actuators for precise control
- Low rotation center runout (≤15µm)
- Different models available with varying travel angles and center heights
- Suitable for fiber alignment and other applications requiring precise angular positioning
Applications
- Fiber alignment and coupling
- Optics research and development
- Laser systems
- Precision optical measurement
- Microscopy
Frequently Asked Questions
What are MGON series high precision goniometers made of?
MGON series high precision goniometers are made of aluminum alloy.
What are the table sizes available for MGON series goniometers?
MGON series goniometers are available in two table sizes: 40×40 mm and 60×60 mm.
What are MGON series goniometers used for?
MGON series goniometers are used for changing the sample's yaw and pitch precisely.
What is the weight of MGON series goniometers?
The weight of MGON series goniometers varies depending on the model, ranging from 0.12 kg to 0.32 kg.
What is the load capacity of MGON series goniometers?
The load capacity of MGON series goniometers ranges from 3 kg to 5 kg.
