Description
NFPG series ultra-high precision goniometers are made of stainless steel. They feature two table sizes 50×50 mm and 70×70 mm. They can change the sample's yaw and pitch precisely.
NFPG series Ultra-High Precision Goniometer
Specifications
| Travel Range: | 0.3 – 7.5 deg |
|---|---|
| Center Of Rotation: | 71.5 mm |
| Load Capacity (horizontal): | 1.5 kg |
| Load Capacity (vertical): | Not Specified |
| Table Size: | 50 mm |
| Guiding Mechanism: | Not Specified |
| Axes Of Motion: | Two Axis |
| Drive Position: | Right Drive |
| Material: | Stainless Steel |
Download Data Sheet
Features
NFPG series Ultra-High Precision Goniometer Stages feature the following:
- Ultra High precision
- Two or axes of control
- Stackable
- Convenient side drive micrometer
- Side lock screw
Applications
NFPG series Ultra-High Precision Goniometer stages are the perfect choice requiring precise angular alignment of optical elements such as crystals, polarizers, lenses and more.
Frequently Asked Questions
What are the table sizes available for the NFPG series Ultra-High Precision Goniometer?
The NFPG series Ultra-High Precision Goniometer is available in two table sizes: 50×50 mm and 70×70 mm.
What are the features of the NFPG series Ultra-High Precision Goniometer Stages?
The NFPG series Ultra-High Precision Goniometer Stages feature ultra-high precision, two or axes of control, stackability, convenient side drive micrometer, and a side lock screw.
What are the applications of the NFPG series Ultra-High Precision Goniometer stages?
The NFPG series Ultra-High Precision Goniometer stages are perfect for precise angular alignment of optical elements such as crystals, polarizers, lenses, and more.
What is the sensitivity of the NFPG-1461U Manual Goniometer?
The sensitivity of the NFPG-1461U Manual Goniometer is 3 ' (arcminutes).
What is the load capacity of the NFPG-1462D Manual Goniometer?
The load capacity of the NFPG-1462D Manual Goniometer is 2.5 kg.
