Thumbnail of PE10B-SI-D0 P/N Photodiode Detector for Laser Energy Measurement photo 1

Description

The PRONTO-500-IPL is a highly capable portable energy meter designed for IPL (Intense Pulsed Light) sources. It replaces the discontinued FLASH-500-55-W-IPL and FLASH-500-55-W-IPL-C models, offering the same measurement capabilities but with enhanced features.

This energy meter provides accurate readings of up to 350 J per pulse and boasts a user-friendly color touch screen display for easy operation. With its large 55 mm aperture, rugged all-metal body, and advanced data logging capabilities, the PRONTO-500-IPL is a versatile tool for measuring and monitoring energy output from IPL sources.

PE10B-SI-D0 P/N Photodiode Detector for Laser Energy Measurement

Visit the Gentec-EO Store

Specifications

Max Measurable Energy: 1.0E-9 mJ
Max Repetition Rate: 1000 Hz
Effective Aperture: 3 mm
Spectral Range: 0.21 – 1.08 um
Typical Rise Time: 30 µs
Typical Energy Sensitivity: 20 mV/J
Noise Equivalent Energy: 1.5 pJ
Maximum Pulse Width: 10 μs
Energy Calibration: ±18 % (210 - 229 nm) ±8.0 % (230 - 254 nm) ±6.5 % (255 - 399 nm) ±2.5 % (400 - 899 nm) ±4.0 % (900 - 1009 nm) ±7.5 % (1010 - 1080 nm)
Maximum Average Power Density: 65 MW/cm²
Maximum Energy Density: 5 µJ/cm²
Maximum Power: 230 μW
Aperture Diameter: 10 mm
Absorber: SiUV
Dimensions: 38.1Ø x 27.4D mm
Weight: 0.09 kg
Distance To Sensor Face: 13.7 mm

Got questions about specs? Use the inquiry form to ask.

Document icon Download Data Sheet Download icon

Features

  • High Energy Per Pulse: Accurate readings up to 350 J per pulse
  • Easy Operation: Features a color touch screen display for intuitive use
  • Large Aperture: Equipped with a 55 mm aperture to accommodate large beams
  • Rugged Build: All-metal body with high damage thresholds for durability
  • Advanced Features: Supports data logging and data transfer to a PC via USB
  • Compatibility: Replaces FLASH-500-55-W-IPL and FLASH-500-55-W-IPL-C models

Applications

  • Ideal for measuring and monitoring energy output from IPL (Intense Pulsed Light) sources
  • Suitable for various applications in cosmetic procedures, medical devices, and light-based treatments
  • Provides accurate energy readings for quality control and safety assurance

Frequently Asked Questions

What is the Gentec-EO Photo Detector used for?
The Gentec-EO Photo Detector is used for measuring laser output energy in the very low energy range of pico Joules per pulse.
What are the available sensors for the PE-B-Si family?
The available sensors for the PE-B-Si family are 3 and 10 mm Ø Silicon sensors for 0.21 to 1.08 μm.
What is the noise level for taking measurements with the M-LINK, MAESTRO and S-LINK monitors?
The noise level for taking measurements with the M-LINK, MAESTRO and S-LINK monitors can be as low as 8 fJ.
What is the calibration uncertainty for the PE10B-Si model?
The calibration uncertainty for the PE10B-Si model is ±8%.
What are the available options for the Gentec-EO Photo Detector?
The standard option for the Gentec-EO Photo Detector is USB Output (-INT), while the in option includes RS-232 Output (-IDR) and External Trigger (-INE).

Got more questions? Use the inquiry form to ask the supplier directly.
