Specifications

Diameter: 0.38″- 0.44″
Lengths Available: 0.38″ to 0.82″
Power Input Range: DC – 0.4 to 1.3 watt @ 25ºC
Operating Voltage: DC operation: up to 45 volts
AC Operation: 26 and 115 volts 400Hz
Rotation: Up to 60º CW or CCW Standard Tolerance + 3
Shutter Blade: Customized per size/shape and surface finish requirements
Document icon Download Data Sheet Download icon

Features

  • Highly reliable and rugged solenoids
  • Customizable to meet exacting client specifications
  • Wide selection of models, sizes, and mounting features available
  • Designed to meet all your application requirements
  • Can operate up to 45 volts for DC and 26/115 volts at 400Hz for AC
  • Available in different diameters and lengths
  • Can rotate up to 60º CW or CCW
  • Customized shutter blade available as per size/shape and surface finish requirements

Applications

  • Industrial automation equipment
  • Automotive systems
  • Aerospace and aviation instrumentation
  • Medical devices
  • Robotics
  • Security systems
  • Gaming and entertainment devices
  • Household appliances
