Zerodur Laser Line Mirrors

Photonchina supplies a wide variety of mirrors, ranging from laser line mirrors, harmonic separator mirrors, high reflection (HR) mirrors, partial reflection mirrors and metallic coated mirrors. Wide selection of rectangular, round, elliptical, or custom shape mirrors with flat, spherical concave or convex and cylindrical surfaces ...

Specifications

Substrate Material: BK7, Supremax 33, Mo, Cu, Si, Metallic, Zerodur, Sapphire, Calcium Fluoride, IR Fused Silica, UV Fused Silica, Fused Silica, Custom
Wavelength Range: 190-4000nm
Angle Of Incidence (AOI): 0-50 deg
Flatness (Coated Surface): lambda/20, lambda/10, lambda/8, lambda/6, lambda/4
Surface Quality: 10-5 scratch-dig, 20-10 scratch-dig, 40-20 scratch-dig, 60-40 scratch-dig
...
Data Sheet
Mirrors are used in a wide range of beam steering, focusing and collimating applications. RMAX Mirrors utilize multi-layer, dielectric thin films. Laser-Line RMAX Mirrors are designed for high reflectance at a single laser wavelength. High power coating designs are standard for select wavelengths. Substrates are available with ...

Specifications

Substrate Material: Zerodur, Supremax 33
Wavelength Range: 193-193nm
Angle Of Incidence (AOI): 0 deg
Flatness (Coated Surface): lambda/20, lambda/10
Surface Quality: 10-5 scratch-dig
...
Data Sheet
On FindLight marketplace you will find 2 different Zerodur Laser Line Mirrors from suppliers around the world. With just a few clicks you can compare different Zerodur Laser Line Mirrors and get accurate price quotes based on your needs and quantity required. Note that some wholesale suppliers may offer discounts for large quantities. From any product page you can directly contact any vendor within seconds.
