Specifications

Gas Medium: CO2, CO
Wavelength: 9.3 um
Output Power: 90 W
Mode Quality (M^2): <1.2
Beam Diameter: 6.5 mm
Beam Divergence (Full Angle): 1.8 mrad
Polarization: Linear
Cooling: Water-to-Water
Power Stability: 5-7 %
Operating Frequency: 0-130 kHz
Duty Cycle Range: 37.5-50 %
Maximum Pulse Length: 1.0-100 μs
DC Voltage Input: 48 VDC
Maximum Current: 48-175 A
Maximum Heat Load: 8.5 kW
Operating Ambient Temperatures: 15-40 °C
Maximum Humidity: 95 %
Document icon Download Data Sheet Download icon

Features


  • Wide range of output powers: 100-400 watts

  • Pulsed CO2 laser technology for precision and control

  • Compact and robust construction for easy integration and durability

  • Designed and engineered by Novanta for exceptional performance

  • Versatile enough to tackle a variety of industrial applications

Applications


  • Laser cutting of metals, plastics, ceramics, and more

  • Precision drilling for micro-machining and borehole creation

  • Laser marking and engraving for product identification and branding

  • Welding and soldering of components in manufacturing processes

  • Surface treatment and texturing for improved adhesion and aesthetics
