Specifications

Gas Medium: CO2
Wavelength: 9.3 um
Output Power: 8 W
Mode Quality (M^2): <1.2
Beam Diameter: 3.5 mm
Beam Divergence (Full Angle): 4 mrad
Polarization: Linear
Cooling: Water-to-Water, Air
Power Stability: 15 %
Operating Frequency: 0-20 kHz
Duty Cycle Range: 0-100 %
Weight: 4.1 kg
Ellipticity: < 1.2
Rise Time: < 150 μs
DC Voltage Input: 30 VDC
Maximum Current: 7.0 A
Maximum Heat Load: 300 W
Operating Ambient Temperatures: 15-40 °C
Maximum Humidity: 80 %
Document icon Download Data Sheet Download icon

Features


  • Proven industry standard for reliability and long lifetime

  • Compact size and lightweight design for easy integration

  • Available in air or water-cooled models

  • Flexible materials processing capability with 10.6 μm and 9.3 μm wavelengths available

  • Reliable 24/7 operation, built with Synrad’s unique rigid core box structure

  • Most popular Synrad laser series, with over 25 years of operational history globally

Applications


  • Fast and easy tracking and identification by applying permanent marks, text, and codes to various materials

  • Application of permanent alphanumeric codes, barcodes, text, and expiration dates to packaging materials

  • Enhancement of tactile experience or quick identification of organic materials through distinctive texture, contours, marks, or text
